Запчасти Komatsu WA180-1LC ГОЛОВКА ЦИЛИНДРОВ ГОЛОВКА ЦИЛИНДРОВ

|$0

1296 013 H91

HEAD ASSEMBLY, CYLINDER

1шт.

1

NSS

HEAD, CYLINDER

1шт.

2

1295 538 H1

PLUG, EXPANSION

5шт.

3

1240 370 H1

PLUG, PIPE

2шт.

4

1239 159 H1

PLUG, PIPE

7шт.

5

1240 127 H1

COLLET, VALVE

24шт.

6

1240 131 H1

SPRING, VALVE

12шт.

7

1240 132 H1

RETAINER, VALVE SPRING

12шт.

8

1240 164 H2

SEAL, VALVE STEM

12шт.

9

1240 104 H92

KIT, INTAKE VALVE

6шт.

10

1240 105 H92

KIT, EXHAUST VALVE

6шт.

11

1239 160 H1

PLUG, PIPE

1шт.

12

1294 507 H2

BOLT

6шт.

13

1294 508 H2

BOLT

14шт.

14

1242 037 H1

GASKET, CYLINDER HEAD

1шт.

15

1240 668 H1

INSERT, VALVE - EXHAUST

-2шт.

16

1240 779 H1

INSERT, VALVE - INTAKE

-2шт.

17

1240 677 H1

GUIDE, VALVE STEM - INTAKE (THICK WALL)

-2шт.

18

1240 678 H1

GUIDE, VALVE STEM - EXHAUST (THICK WALL)

-2шт.

19

1240 763 H1

GUIDE, VALVE STEM - INT/EXH (THIN WALL)

-2шт.

|$20

1294 396 H2

GASKET, CYLINDER HEAD - 0.15MM

1шт.

|$21

1240 728 H3

GASKET, CYLINDER HEAD - 0.50MM

1шт.

|$24

-1шт.

|$23

F1 - INCLUDED IN INTAKE & EXHAUST VALVE KITS

-1шт.

|$25

-1шт.
