Запчасти Komatsu WA180-1LC КОНДИЦ. ВОЗДУХА - заводской номер A7 THRU A7 COMPLETE ASSEMBLY И КРЕПЛЕНИЕ РАМА

|$0

417-963-3200

AIR CONDITIONING UNIT

1шт.

1

417-963-3110

AIR CONDITIONER

1шт.

2

01435-01220

BOLT, MOUNT AIR CONDITIONER

4шт.

3

417-963-3410

BRACKET, MOUNT AIR CONDITIONER

1шт.

4

01435-01020

BOLT, MOUNT BRACKET

5шт.

5

FILTER BOX ASSEMBLY (SEE PG 05-122)

-29шт.

6

421-07-12312

GRILLE ASSEMBLY

1шт.

7

09415-02110

GROMMET, FILTER BOX

1шт.

8

01435-01020

BOLT, MOUNT FILTER BOX

2шт.

9

AIR DUCT ASSEMBLY (SEE PG 05-120)

-29шт.

10

01435-01016

BOLT, MOUNT AIR DUCT

2шт.

11

417-963-3420

BRACKET, MOUNT AIR DUCT

1шт.

12

01435-01035

BOLT, MOUNT BRACKET TO FLOOR

2шт.

13

417-963-3120

CONTROL LEVER ASSEMBLY

1шт.

14

417-963-3130

CABLE, CONTROL LEVER

4шт.

15

417-963-3770

INSULATION

1шт.

16

CLAMP, DRAIN HOSE (SEE PG 05-098)

-29шт.

17

HOSE, DRAIN (SEE PG 05-098)

-29шт.

|$21

-1шт.

|$19

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED

-1шт.

|$20

FOR REFERENCE ONLY, ORDER INDIVIDUAL PIECE PARTS.

-1шт.
