Запчасти Komatsu WA180-1LC КРЫЛОS И ЛЕСТНИЦАS РАМА

1

417-54-11523

FENDER, LH FRONT

1шт.

2

417-54-11513

FENDER, RH FRONT

1шт.

3

01010-51235

BOLT, MOUNT FRONT FENDERS

8шт.

4

01580-01210

NUT

8шт.

5

01643-31232

WASHER

16шт.

6

416-54-14910

FENDER, LH REAR

1шт.

7

416-54-14920

FENDER, RH REAR

1шт.

8

01010-51245

BOLT, MOUNT REAR FENDERS

8шт.

9

01643-31232

WASHER

8шт.

10

416-54-14170

COVER, LH (W/O AIR CONDITIONING)

1шт.

|$10

416-963-A050

COVER, LH (W/EAGLE AIR CONDITIONER)

1шт.

11

417-54-A1650

COVER, RH (W/O GROUND DRIVEN STEERING)

1шт.

|$12

417-875-A110

COVER, RH (W/GROUND DRIVEN STEERING)

1шт.

12

01010-51225

BOLT, MOUNT COVERS

8шт.

13

01643-31232

WASHER

8шт.

14

416-54-14930

COVER, LH

1шт.

15

416-54-14940

COVER, RH

1шт.

16

01010-51225

BOLT, MOUNT COVERS

6шт.

17

01643-31232

WASHER

6шт.

18

416-54-14132

BOX, TOOL

1шт.

19

01010-51225

BOLT, MOUNT TOOL BOX

4шт.

20

01643-31232

WASHER

4шт.

21

416-54-14111

LADDER, ENTRY - LH SIDE

1шт.

22

416-54-14230

BRACKET

1шт.

23

01010-51235

BOLT, MOUNT LADDER TO FENDER AND BRACKET

4шт.

24

01643-31232

WASHER

4шт.

25

416-54-14650

STEP, ENTRY - RH SIDE

2шт.

26

01010-51230

BOLT, MOUNT STEPS

4шт.

27

01643-31232

WASHER

4шт.

28

417-54-13620

BRACKET, MOUNT LADDER TO FENDER

1шт.

29

01435-01225

BOLT, MOUNT BRACKET TO FENDER

2шт.

30

01580-01210

NUT

2шт.

31

01643-31232

WASHER

2шт.

32

416-54-15130

RAIL, HAND - LH

1шт.

33

416-54-15140

RAIL, HAND - RH

1шт.

34

01010-51235

BOLT, MOUNT HAND RAILS

2шт.

35

01010-51230

BOLT, MOUNT HAND RAILS

2шт.

36

01643-31232

WASHER

4шт.

|$50

-1шт.

|$39

F1 - USED ON MACHINES NOT EQUIPPED WITH EAGLE AIR

-1шт.

|$40

CONDITIONER.

-1шт.

|$51

-1шт.

|$42

F2 - USED ON MACHINES EQUIPPED WITH EAGLE AIR

-1шт.

|$43

CONDITIONER - S/N A75654 AND UP.

-1шт.

|$52

-1шт.

|$45

F3 - USED ON MACHINES NOT EQUIPPED WITH GROUND

-1шт.

|$46

DRIVEN STEERING.

-1шт.

|$53

-1шт.

|$48

F4 - USED ON MACHINES EQUIPPED WITH GROUND DRIVEN

-1шт.

|$49

STEERING.

-1шт.
