Запчасти Komatsu WA150L-5 НАСОС (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$$1

PARTS MARKED B6, CANNNOT BE SUPPLIED AS AN INDIVIDUAL PART.IT IS SUPPLIED AS A S ET OF OTHER PARTS MARKED B6.

-1шт.

|$$2

PARTS MARKED B7, CANNNOT BE SUPPLIED AS AN INDIVIDUAL PART.IT IS SUPPLIED AS A S ET OF OTHER PARTS MARKED B7.

-1шт.

|$3

416-18-31601

PUMP

SN: 65061-UP

1шт.

|$4

0

GEAR PUMP

SN: 65061-UP

1шт.

1

UC1096511474

FLANGE B6

SN: 65061-UP

1шт.

2

UC1020779462

COVER B6

SN: 65061-UP

1шт.

3

UC1704491361

METAL B6

SN: 65061-UP

1шт.

4

UC1096503877

DRIVE SHAFT B7

SN: 65061-UP

1шт.

5

UC4020062587

GEAR B6

SN: 65061-UP

1шт.

6

UC1720256499

KEY B7

SN: 65061-UP

1шт.

7

UC1701569306

RING

SN: 65061-UP

1шт.

8

UC1090830605

BOLT

SN: 65061-UP

4шт.

9

UC1700831903

BOLT

SN: 65061-UP

8шт.

10

UC1300305002

O-RING

SN: 65061-UP

1шт.

11

UC1701524936

SEAL

SN: 65061-UP

8шт.

12

UC1303046825

O-RING

SN: 65061-UP

1шт.

13

UC1300301009

O-RING

SN: 65061-UP

1шт.
