Запчасти Komatsu WA150-6 МАРКИРОВКА, EXTERIOR (№8-) МАРКИРОВКА, АНГЛ., TEXT ТИП

1

11Y-98-31150

Plate, Danger, Keep Away from Machine

SN: 80001-UP

2шт.

2

09807-C0883

Plate, Danger, Keep Out under Work Equipment

SN: 80001-UP

2шт.

3

09808-03000

Plate, Warning, Battery Cables

SN: 80001-UP

2шт.

4

09161-23000

Plate, Warning, Articulation Lock

SN: 80001-UP

1шт.

5

09162-23000

Plate, Danger, Keep Off

SN: 80001-UP

2шт.

6

09653-03001

Plate, Warning, High Temperature

SN: 80001-UP

1шт.

7

09667-03001

Plate, Caution, Rotating Object

SN: 80001-UP

2шт.

8

416-93-31572

Decal, Machine Model

SN: 80001-UP

1шт.

9

416-93-31582

Decal, Machine Model

SN: 80001-UP

1шт.

10

416-93-41520

Lubrication Chart

SN: 80001-UP

1шт.

11

09960-01601

Mark, Lift Point and Tie Down Point Marks

SN: 80001-UP

4шт.

11

418-93-22240

Decal

SN: 80001-UP

1шт.

12

Decal

SN: 80001-UP

1шт.

13

Decal

SN: 80001-UP

1шт.

14

09652-31221

Plate, Caution, Diesel Fuel

SN: 80001-UP

1шт.

15

418-93-42410

Plate, Stripe

SN: 80001-UP

4шт.

16

418-93-43341

Plate, Caution Cleaning Core

SN: 80001-UP

1шт.

17

09690-P0630

Plate, Komatsu Logo

SN: 80001-UP

2шт.

18

20Y-00-41530

Plate, Symbol, Ecot3

SN: 80001-UP

1шт.

19

09668-03001

Plate, Warning, Hot Water

SN: 80001-UP

1шт.

20

421-93-A1510

Plate

SN: 80001-UP

1шт.

21

09963-03001

Tag, Danger, Do Not Operate

SN: 80001-UP

1шт.

22

09664-30011

Plate, Danger, Battery

SN: 80001-UP

2шт.

23

416-93-41540

Plate

SN: 80001-UP

2шт.

24

09659-53000

Plate, Warning, Explosion Hazard

SN: 80001-UP

5шт.
