Артикул
Название
Примечание
Количество
|$$1
PARTS MARKED B8, CANNNOT BE SUPPLIED AS AN INDIVIDUAL PART.IT IS SUPPLIED AS A S ET OF OTHER PARTS MARKED B8.
-1шт.
|$3
416-18-31602
PUMP
SN: 77149-UP
1шт.
|$$4
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1610-11A0 TO Y1610-25A0.
-1шт.
|$6
UC4720449442
VALVE BLOCK ASS'Y
SN: 65001-UP
1шт.
1
UC1720405793
BODY B8
SN: 65001-UP
1шт.
2
UC1720448598
SPOOL
SN: 65001-UP
1шт.
3
UC1720406943
SPRING SEAT
SN: 65001-UP
2шт.
4
UC1700713621
SPRING
SN: 65001-UP
2шт.
5
UC1708313476
PLUG B8
SN: 65001-UP
1шт.
6
UC1701538797
PLUG B8
SN: 65001-UP
2шт.
7
UC1020666119
GASKET
SN: 65001-UP
1шт.
8
UC1700830276
BOLT
SN: 65001-UP
3шт.
9
UC1708300407
BOLT
SN: 65001-UP
2шт.
10
UC1300126001
O-RING
SN: 65001-UP
1шт.
Выбрано товаров: 15
