Запчасти Komatsu WA150-5 НАСОС (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$$1

PARTS MARKED B4, CANNNOT BE SUPPLIED AS AN INDIVIDUAL PART.IT IS SUPPLIED AS A S ET OF OTHER PARTS MARKED B4.

-1шт.

|$$2

PARTS MARKED B5, CANNNOT BE SUPPLIED AS AN INDIVIDUAL PART.IT IS SUPPLIED AS A S ET OF OTHER PARTS MARKED B5.

-1шт.

|$4

416-18-31602

PUMP

SN: 77149-UP

1шт.

|$5

0

PUMP

SN: 65001-77148

1шт.

|$$5

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1610-11A0 TO Y1610-25A0.

-1шт.

|$7

UC4100693926

PLATE

SN: 65001-UP

1шт.

1

0

RELIEF VALVE

SN: 65001-UP

2шт.

2

0

RELIEF VALVE

SN: 65001-UP

1шт.

3

0

CUT-OFF VALVE

SN: 65001-UP

1шт.

4

UC1100679226

COVER B4

SN: 65001-UP

1шт.

5

UC1704491361

METAL B4

SN: 65001-UP

1шт.

6

UC1301638009

BOLT

SN: 65001-UP

4шт.

7

UC1301302004

O-RING

SN: 65001-UP

1шт.

8

UC1701538797

PLUG B4

SN: 65001-UP

2шт.

9

UC1701533646

PLUG

SN: 65001-UP

1шт.

10

UC1300030001

O-RING

SN: 65001-UP

1шт.

11

UC4100104426

PLUG

SN: 65001-UP

2шт.

11

UC1198273603

PLUG

SN: 65001-UP

1шт.

11

UC1301169009

O-RING

SN: 65001-UP

1шт.

12

UC1704448422

BUSHING B5

SN: 65001-UP

1шт.

13

UC1704266541

METAL B5

SN: 65001-UP

1шт.

14

UC1300038005

O-RING

SN: 65001-UP

2шт.

15

UC1701538807

PLUG B4

SN: 65001-UP

2шт.
