Запчасти Komatsu WA150-5 НАСОС (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$$1

PARTS MARKED B1, CANNNOT BE SUPPLIED AS AN INDIVIDUAL PART.IT IS SUPPLIED AS A S ET OF OTHER PARTS MARKED B1.

-1шт.

|$3

416-18-31602

PUMP

SN: 77149-UP

1шт.

|$4

0

PUMP

SN: 65001-77148

1шт.

|$$4

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1610-11A0 TO Y1610-25A0.

-1шт.

1

0

ROTARY GROUP

SN: 65001-UP

1шт.

2

0

HD CONTROL

SN: 65001-UP

1шт.

3

0

PLATE

SN: 65001-UP

1шт.

4

0

GEAR PUMP ASS'Y

SN: 65001-UP

1шт.

5

0

VALVE

SN: 65001-UP

1шт.

6

0

DA CARTRIDGE ASS'Y

SN: 65001-UP

1шт.

7

UC1100679849

HOUSING B1

SN: 65001-UP

1шт.

8

UC1704497149

PIN

SN: 65001-UP

2шт.

9

UC4100104453

PLUG

SN: 65001-UP

1шт.

9

0

PLUG

SN: 65001-UP

1шт.

9

UC1301205004

O-RING

SN: 65001-UP

1шт.

10

UC4100104426

PLUG

SN: 65001-UP

4шт.

10

0

PLUG

SN: 65001-UP

1шт.

10

UC1301169009

O-RING

SN: 65001-UP

1шт.

11

UC1701538797

PLUG B1

SN: 65001-UP

1шт.

12

UC1701565799

SPRING PIN B1

SN: 65001-UP

2шт.

13

UC1701533646

PLUG

SN: 65001-UP

2шт.

14

UC4100104444

PLUG

SN: 65001-UP

1шт.

14

0

PLUG

SN: 65001-UP

1шт.

14

UC1301190003

O-RING

SN: 65001-UP

1шт.

15

UC1700879134

PLUG

SN: 65001-UP

1шт.

16

0

SCREW

SN: 65001-UP

1шт.

17

0

NUT

SN: 65001-UP

1шт.

18

UC1701564979

ORIFICE

SN: 65001-UP

1шт.

19

UC1701564934

ORIFICE

SN: 65001-UP

1шт.
