Запчасти Komatsu WA150-3-X КОВШ(№-) КАТАЛОГИ ЗЧ

|$$1

1.4M3 BUCKET

SN: 12001-UP

-1шт.

|$$2

1.5M3 BUCKET{(WITH BOLT ON CUTTING EDGE)}

SN: 12001-UP

-1шт.

1

417-70-22110

BUCKET

SN: 10001-UP

1шт.

2

417-70-22120

PLATE (WELDED)

SN: 12001-UP

2шт.

3

417-70-12121

EDGE (WELDED)

SN: 12001-UP

1шт.

4

416-70-12A51

PLATE (WELDED)

SN: 10001-UP

2шт.

5

417-70-12B22

PLATE (WELDED)

SN: 12001-UP

2шт.

|$$8

EXCAVATING BUCKET

SN: 10001-UP

-1шт.

|$$9

1.2M3 BUCKET

SN: 12001-UP

-1шт.

|$$10

1.3M3 BUCKET{(WITH BOLT ON CUTTING EDGE)}

SN: 12001-UP

-1шт.

1

417-806-2110

BUCKET

SN: 12001-UP

1шт.

2

416-70-22120

PLATE (WELDED)

SN: 10001-UP

2шт.

3

417-70-12121

EDGE (WELDED)

SN: 60001-UP

1шт.

4

416-70-12A51

PLATE (WELDED)

SN: 60001-UP

2шт.

5

416-70-12B22

PLATE (WELDED)

SN: 60001-UP

2шт.

|$$16

LIGHT MATERIAL{(FOR COUPLER BUCKET)}

-1шт.

|$$17

1.4M3 BUCKET

-1шт.

|$$18

1.5M3 BUCKET{(WITH BOLT ON CUTTING EDGE)}

-1шт.

6

417-840-1102

BUCKET ASS'Y

SN: 60001-UP

1шт.

7

417-70-12132

PLATE (WELDED)

SN: 60001-UP

2шт.

8

417-70-12121

EDGE (WELDED)

SN: 60001-UP

1шт.

9

417-70-12240

PLATE,L.H. (WELDED)

SN: 60001-UP

1шт.

10

417-70-12250

PLATE,R.H. (WELDED)

SN: 60001-UP

1шт.
