Запчасти Komatsu WA150-3-SN ГИДРОТРАНСФОРМАТОР ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

714-11-10003

TRANSMISSION ASS'Y

SN: (68569)-UP

1шт.

|1

714-11-10002

TRANSMISSION ASS'Y

SN: (67311)-(68568)

1шт.

|1

714-11-10001

TRANSMISSION ASS'Y

SN: 63151-(67310)

1шт.

|1

714-11-10000

TRANSMISSION ASS'Y

SN: 63001-63150

1шт.

|1

714-11-10043

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: (68573)-UP

1шт.

|1

714-11-10042

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: (67408)-(68572)

1шт.

|1

714-11-10041

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 63151-(67407)

1шт.

|1

714-11-10040

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 63001-63150

1шт.

|$$10

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-67A0.

-1шт.

|1

711-58-00300

TORQUE CONVERTER A.

SN: 63001-UP

1шт.

1

01010-80825

BOLT

SN: 63001-UP

24шт.

2

01643-30823

WASHER

SN: 63001-UP

24шт.

3

711-58-42521

SHAFT

SN: 63001-UP

1шт.

4

07018-31004

RING,SEAL

SN: 63001-UP

1шт.

5

04064-07025

RING,SNAP

SN: 63001-UP

1шт.

6

06040-06217

BEARING

SN: 63001-UP

1шт.

7

01010-81055

BOLT

SN: 63001-UP

8шт.

8

01643-31032

WASHER

SN: 63001-UP

8шт.

9

711-58-11120

PUMP

SN: 63001-UP

1шт.

|10

711-58-21510

TURBINE ASS'Y

SN: 63001-UP

1шт.

10

0

TURBINE

SN: 63001-UP

1шт.

11

0

BOSS

SN: 63001-UP

1шт.

12

0

PLATE

SN: 63001-UP

1шт.

13

0

RIVET

SN: 63001-UP

8шт.

14

711-58-12110

STATOR

SN: 63001-UP

1шт.

15

06043-06011

BEARING

SN: 63001-UP

1шт.

16

711-01-11570

RING,SNAP

SN: 63001-UP

1шт.

17

01010-81025

BOLT

SN: 63001-UP

6шт.

18

01643-31032

WASHER

SN: 63001-UP

6шт.

19

711-55-11210

CASE

SN: 63001-UP

1шт.

20

711-55-11250

PILOT

SN: 63001-UP

1шт.

21

711-58-41141

GEAR

SN: 63001-UP

1шт.
