Артикул
Название
Примечание
Количество
|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|1
714-11-10003
TRANSMISSION ASS'Y
SN: (68569)-UP
1шт.
|1
714-11-10002
TRANSMISSION ASS'Y
SN: (67311)-(68568)
1шт.
|1
714-11-10043
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: (68573)-UP
1шт.
|1
714-11-10042
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: (67408)-(68572)
1шт.
|$$6
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-67A0.
-1шт.
|1
714-11-15031
VALVE ASS'Y
SN: (68611)-UP
1шт.
|1
714-11-15030
CONTROL VALVE ASS'Y
SN: (67749)-(68610)
1шт.
|$$9
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-60A0 TO F4350-62A0.
-1шт.
|1
714-11-16200
VALVE ASS'Y,LOWER
SN: (67749)-UP
1шт.
|$$11
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-61A0A AND 62A0A.
-1шт.
1
419-15-16521
BODY,LOWER
SN: 63001-UP
1шт.
2
419-15-16530
COVER
SN: 63001-UP
1шт.
3
419-15-16541
GASKET (K2)
SN: 63001-UP
1шт.
4
419-15-16551
GASKET (K2)
SN: 63001-UP
1шт.
5
419-15-16560
VALVE,T/C REGULATOR SELECTOR
SN: 63001-UP
1шт.
6
714-11-15210
VALVE,FORWARD AND REVERSE SELECTOR
SN: 63001-UP
1шт.
7
714-11-15230
VALVE,H-L SELECTOR
SN: 63001-UP
1шт.
8
714-11-15220
VALVE,SPEED SELECTOR
SN: 63001-UP
1шт.
9
419-15-16610
SPRING,T/C REGULATOR SELECTOR
SN: 63001-UP
1шт.
11
419-15-16631
SPACER,SPRING
SN: 63001-UP
2шт.
12
02720-10104
PLUG
SN: 63001-UP
1шт.
13
419-15-16640
RETAINER,SPRING
SN: 63001-UP
1шт.
14
419-15-16650
SHIM¤ 1.0MM
SN: 63001-UP
5шт.
15
417-15-17191
SLEEVE
SN: (67036)-UP
2шт.
16
417-15-17280
SPRING
SN: 63001-UP
2шт.
20
419-15-15640
PLUG
SN: 63001-UP
1шт.
21
415-15-15430
PLUG
SN: 63001-UP
1шт.
Выбрано товаров: 32
