Запчасти Komatsu WA150-3-SN КЛАПАН УПРАВЛЕНИЯ ТРАНСМИССИЕЙ (/) (НИЖНИЙ КЛАПАН)(№-(778)) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

714-11-10002

TRANSMISSION ASS'Y

SN: (67311)-@

1шт.

|1

714-11-10001

TRANSMISSION ASS'Y

SN: 63151-(67310)

1шт.

|1

714-11-10000

TRANSMISSION ASS'Y

SN: 63001-63150

1шт.

|1

714-11-10042

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: (67408)-@

1шт.

|1

714-11-10041

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 63151-(67407)

1шт.

|1

714-11-10040

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 63001-63150

1шт.

|$$8

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-67A0.

-1шт.

|1

714-11-15020

CONTROL VALVE ASS'Y

SN: (66916)-(67748)

1шт.

|1

714-11-15011

CONTROL VALVE ASS'Y

SN: (66468)-(66915)

1шт.

|1

714-11-15010

CONTROL VALVE ASS'Y

SN: 63001-(66467)

1шт.

|$$12

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-60A0 TO F4350-62A0.

-1шт.

|1

714-11-16101

VALVE ASS'Y,LOWER

SN: (67036)-(67748)

1шт.

|1

714-11-16100

VALVE ASS'Y,LOWER

SN: 63001-(67035)

1шт.

|$$15

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F4350-61A0 AND F4350-62A0.

-1шт.

1

419-15-16521

BODY,LOWER

SN: 63001-@

1шт.

2

419-15-16530

COVER

SN: 63001-@

1шт.

3

419-15-16541

GASKET (K2)

SN: 63001-@

1шт.

4

419-15-16551

GASKET (K2)

SN: 63001-@

1шт.

5

419-15-16560

VALVE,T/C REGULATOR SELECTOR

SN: 63001-@

1шт.

6

714-11-15210

VALVE,FORWARD AND REVERSE SELECTOR

SN: 63001-@

1шт.

7

714-11-15230

VALVE,H-L SELECTOR

SN: 63001-@

1шт.

8

714-11-15220

VALVE,SPEED SELECTOR

SN: 63001-@

1шт.

9

419-15-16610

SPRING,T/C REGULATOR SELECTOR

SN: 63001-@

1шт.

10

419-15-16620

SPRING,RETURN

SN: 63001-@

2шт.

11

419-15-16631

SPACER,SPRING

SN: 63001-@

2шт.

12

02720-10104

PLUG

SN: 63001-@

1шт.

13

419-15-16640

RETAINER,SPRING

SN: 63001-@

1шт.

14

419-15-16650

SHIM¤ 1.0MM

SN: 63001-@

5шт.

15

417-15-17191

SLEEVE

SN: (67036)-@

2шт.

|15

417-15-17190

SLEEVE

SN: 63001-(67035)

2шт.

16

417-15-17280

SPRING

SN: 63001-@

2шт.

17

07042-30108

PLUG

SN: 63001-@

1шт.

18

01010-31030

BOLT

SN: 63001-@

2шт.

19

01010-31055

BOLT

SN: 63001-@

7шт.

20

419-15-15640

PLUG

SN: 63001-@

1шт.

21

415-15-15430

PLUG

SN: 63001-@

1шт.
