Запчасти Komatsu WA150-3-SN КЛАПАН УПРАВЛЕНИЯ ТРАНСМИССИЕЙ (/) (КРЕПЛЕНИЕ) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

714-11-10003

TRANSMISSION ASS'Y

SN: (68569)-UP

1шт.

|1

714-11-10002

TRANSMISSION ASS'Y

SN: (67311)-(68568)

1шт.

|1

714-11-10001

TRANSMISSION ASS'Y

SN: 63151-(67310)

1шт.

|1

714-11-10000

TRANSMISSION ASS'Y

SN: 63001-63150

1шт.

|1

714-11-10043

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: (68573)-UP

1шт.

|1

714-11-10042

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: (67408)-(68572)

1шт.

|1

714-11-10041

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 63151-(67407)

1шт.

|1

714-11-10040

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 63001-63150

1шт.

|$$10

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-67A0.

-1шт.

1

714-11-15031

VALVE ASS'Y

SN: (68611)-UP

1шт.

|1

714-11-15030

CONTROL VALVE ASS'Y

SN: (67749)-(68610)

1шт.

|1

714-11-15020

CONTROL VALVE ASS'Y

SN: (66916)-(67748)

1шт.

|1

714-11-15011

CONTROL VALVE ASS'Y

SN: (66468)-(66915)

1шт.

|1

714-11-15010

CONTROL VALVE ASS'Y

SN: 63001-(66467)

1шт.

2

714-11-16920

GASKET,LOWER (K2)

SN: 63001-UP

1шт.

3

01011-81020

BOLT

SN: 63001-UP

4шт.

4

01011-81030

BOLT

SN: 63001-UP

2шт.

5

01011-81035

BOLT

SN: 63001-UP

2шт.

6

419-15-16680

BOLT

SN: 63001-UP

4шт.

7

419-15-15170

BOLT

SN: 63001-UP

1шт.

8

714-11-15600

VALVE ASS'Y,ACCUMULATOR

SN: 63001-UP

1шт.

9

01010-81070

BOLT

SN: 63001-UP

2шт.

10

07000-73025

O-RING (K2)

SN: 63001-UP

2шт.

11

07000-72014

O-RING (K2)

SN: 63001-UP

2шт.
