Запчасти Komatsu WA150-3-SN ТРАНСМИССИЯ (МЕХ-М ОТБОРА МОЩН-ТИ) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

714-11-10003

TRANSMISSION ASS'Y

SN: (68569)-UP

1шт.

|1

714-11-10002

TRANSMISSION ASS'Y

SN: (67311)-(68568)

1шт.

|1

714-11-10001

TRANSMISSION ASS'Y

SN: 63151-(67310)

1шт.

|1

714-11-10000

TRANSMISSION ASS'Y

SN: 63001-63150

1шт.

|1

714-11-10043

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: (68573)-UP

1шт.

|1

714-11-10042

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: (67408)-(68572)

1шт.

|1

714-11-10041

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 63151-(67407)

1шт.

|1

714-11-10040

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 63001-63150

1шт.

|$$10

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-67A0.

-1шт.

1

714-11-13211

SHAFT

SN: 63001-UP

1шт.

2

06040-06010

BEARING

SN: 63001-UP

1шт.

3

714-11-19350

BEARING,NEEDLE

SN: 63001-UP

1шт.

4

04065-08025

RING,SNAP

SN: 63001-UP

1шт.

5

714-11-13411

GEAR¤ 67 TEETH

SN: 63001-UP

1шт.

6

04065-04718

RING,SNAP

SN: 63001-UP

1шт.

7

714-11-13220

SHAFT

SN: 63001-UP

1шт.

8

06040-06210

BEARING

SN: 63001-UP

1шт.

9

714-11-19350

BEARING,NEEDLE

SN: 63001-UP

1шт.

10

04065-09030

RING,SNAP

SN: 63001-UP

1шт.

11

714-11-13420

GEAR¤ 75 TEETH

SN: 63001-UP

1шт.

12

04065-04718

RING,SNAP

SN: 63001-UP

1шт.

13

714-11-13720

SPACER

SN: 63001-UP

4шт.

14

714-11-13710

RING

SN: 63001-UP

2шт.

15

04064-05020

RING,SNAP

SN: 63001-UP

2шт.
