Запчасти Komatsu WA150-3 КЛАПАН АККУМУЛЯТОРА ТРАНСМИССИИ ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

714-11-10003

TRANSMISSION ASS'Y

SN: (68569)-UP

1шт.

|1

714-11-10002

TRANSMISSION ASS'Y

SN: (67311)-(68568)

1шт.

|1

714-11-10001

TRANSMISSION ASS'Y

SN: 63151-(67310)

1шт.

|1

714-11-10000

TRANSMISSION ASS'Y

SN: 63001-63150

1шт.

|1

714-11-10043

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: (68573)-UP

1шт.

|1

714-11-10042

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: (67408)-(68572)

1шт.

|1

714-11-10041

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 63151-(67407)

1шт.

|1

714-11-10040

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 63001-63150

1шт.

|$$10

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-67A0.

-1шт.

|1

714-11-15600

VALVE ASS'Y,ACCUMULATOR

SN: 63001-UP

1шт.

1

714-11-15160

BODY,VALVE

SN: 63001-UP

1шт.

2

714-11-15830

COVER,VALVE

SN: 63001-UP

1шт.

3

714-11-15260

VALVE

SN: 63001-UP

3шт.

4

714-07-16490

SPRING

SN: 63001-UP

1шт.

5

714-07-16490

SPRING

SN: 63001-UP

2шт.

6

714-11-15480

SPACER

SN: 63001-UP

2шт.

7

714-11-15470

SPACER

SN: 63001-UP

1шт.

8

714-11-15380

STOPPER

SN: 63001-UP

1шт.

9

714-11-15380

STOPPER

SN: 63001-UP

2шт.

10

01252-31025

BOLT

SN: 63001-UP

4шт.

11

07000-03038

O-RING (K2)

SN: 63001-UP

3шт.

12

07000-02014

O-RING (K2)

SN: 63001-UP

1шт.

13

07043-70108

PLUG

SN: 63001-UP

2шт.
