Артикул
Название
Примечание
Количество
|$0
TRANSMISSION ASSEMBLY (SEE FIG. F4350-51A0)
SN: A31001--UP
1шт.
|$1
CONTROL VALVE ASSEMBLY (SEE FIG. F4350-59A0)
SN: A31001--UP
1шт.
|$2
714-11-15100
VALVE ASSEMBLY, UPPER
SN: A31001--UP
1шт.
1
419-15-15711
BODY, UPPER
SN: A31001--UP
1шт.
2
419-15-15720
COVER
SN: A31001--UP
1шт.
3
419-15-15730
COVER
SN: A31001--UP
1шт.
4
419-15-15741
GASKET
SN: A31001--UP
1шт.
5
419-15-15751
GASKET
SN: A31001--UP
1шт.
6
419-15-15760
VALVE, PILOT
SN: A31001--UP
1шт.
7
714-11-15311
VALVE, MAIN
SN: A31001--UP
1шт.
8
419-15-15780
VALVE, PRIORITY
SN: A31001--UP
1шт.
9
419-15-15790
VALVE, ACCUMULATOR
SN: A31001--UP
1шт.
10
419-15-15810
VALVE, MODULATE
SN: A31001--UP
1шт.
11
419-15-15820
PISTON, LOAD
SN: A31001--UP
1шт.
12
419-15-15830
PISTON, LOAD
SN: A31001--UP
1шт.
13
419-15-15840
VALVE, QUICK RETURN
SN: A31001--UP
1шт.
14
419-15-15850
PLUG, VALVE
SN: A31001--UP
1шт.
15
419-15-15860
SLEEVE, MODULATE
SN: A31001--UP
1шт.
16
419-15-15870
SHAFT, ACCUMULATOR
SN: A31001--UP
1шт.
17
419-15-15910
SPRING, MAIN
SN: A31001--UP
1шт.
18
419-15-15920
SPRING, PRIORITY
SN: A31001--UP
1шт.
19
419-15-15940
SPRING, INNER MODULATE
SN: A31001--UP
1шт.
20
419-15-15930
SPRING, OUTER MODULATE
SN: A31001--UP
1шт.
21
419-15-15950
SPRING, OUTER ACCUMULATOR
SN: A31001--UP
1шт.
22
419-15-15960
SPRING, INNER ACCUMULATOR
SN: A31001--UP
1шт.
23
419-15-15970
SPRING, INNER ACCUMULATOR
SN: A31001--UP
1шт.
24
419-15-15880
ROD, ADJUST
SN: A31001--UP
1шт.
25
419-15-15890
PLUG, MODULATE
SN: A31001--UP
1шт.
26
419-15-15980
RETAINER, MODULATE
SN: A31001--UP
1шт.
28
419-15-15510
SPRING, CHECK
SN: A31001--UP
1шт.
29
419-15-15640
PLUG
SN: A31001--UP
1шт.
34
417-15-15842
ORIFICE, MAIN
SN: A31001--UP
1шт.
Выбрано товаров: 41
