Запчасти Komatsu WA120-3MC FIG. U-A МАРКИРОВКА - С КАБИНОЙ (АНГЛ.) МАРКИРОВКА

|$0

417-93-21310

PLATE KIT

SN: A31001--UP

1шт.

1

NSS

PLATE, SAFETY, KEEP OUT

SN: A31001--UP

2шт.

2

NSS

PLATE, SAFETY, SAFETY BAR

SN: A31001--UP

1шт.

3

NSS

PLATE, INSTRUCTION, FUEL

SN: A31001--UP

1шт.

4

NSS

PLATE, SAFETY, RADIATOR CAP

SN: A31001--UP

1шт.

5

NSS

PLATE, INSTRUCTION, ENGINE OIL

SN: A31001--UP

1шт.

6

NSS

PLATE, SAFETY, BRAKE OIL

SN: A31001--UP

1шт.

7

NSS

PLATE, SAFETY, HYDRAULIC TANK CAP

SN: A31001--UP

1шт.

8

NSS

PLATE, SAFETY, BATTERY CABLE

SN: A31001--UP

1шт.

9

417-93-21141

PLATE, MARK, KOMATSU

SN: A31001--UP

1шт.

10

417-93-21150

PLATE, STRIPE, L.H.

SN: A31001--UP

1шт.

11

417-93-21160

PLATE, STRIPE, R.H.

SN: A31001--UP

1шт.

12

416-93-21210

PLATE, MARK, WA120

SN: A31001--UP

2шт.

13

417-93-21220

PLATE, MARK, AVANCE LOADER

SN: A31001--UP

2шт.

14

416-93-21231

CHART, OIL

SN: A31001--UP

1шт.

15

09806-C0880

PLATE, CAUTION, KEEP DISTANCE

SN: A31001--UP

2шт.

16

09667-A0880

PLATE, SAFETY, FAN

SN: A31001--UP

2шт.

17

09807-C0880

PLATE, SAFETY, KEEP OUT

SN: A31001--UP

2шт.

18

09960-01001

PLATE, MARK HANDLING, LIFT HERE

SN: A31001--UP

2шт.

19

416-93-A1320

DECAL, AVANCE, HOOD

SN: A31001--UP

2шт.

20

416-93-A1340

DECAL, PLUS, HOOD

SN: A31001--UP

2шт.

21

09812-13000

PLATE, SAFETY

SN: A31001--UP

2шт.

22

09690-D0800

DECAL, KOMATSU, BOOM

SN: A31001--UP

2шт.

23

09812-13000

PLATE, SAFETY

SN: A31001--UP

2шт.

24

419-93-A2310

DECAL, REAR WINDOW

SN: A31001--UP

1шт.

25

418-93-A2330

DECAL, FRONT WINDOW

SN: A31001--UP

1шт.

26

09667-03001

PLATE, SAFETY, FAN

SN: A31001--UP

2шт.

27

09690-C0450

DECAL, WINDOW

SN: A31001--UP

2шт.

28

419-93-A2130

DECAL, BATTERY BOOSTER

SN: A31001--UP

1шт.
