Запчасти Komatsu WA120-3L ШАТУН И ПОРШЕНЬ ДВИГАТЕЛЬ

|$0

6732-31-3101

ENGINE CONNECTING ROD ASSY

4шт.

1

NSS

ROD, ENGINE CONNECTING

1шт.

2

6732-31-3310

BOLT, ROD CAP

2шт.

3

6732-31-3131

BUSHING

1шт.

4

6732-31-3410

BEARING, CONNECTING ROD (STANDARD)

8шт.

|$5

6735-31-2140

KIT, ENGINE PISTON

4шт.

5

NSS

PISTON, ENGINE

1шт.

6

6736-31-2510

RING, RETAINING

2шт.

7

6735-31-2030

SET, PISTON RING

1шт.

8

6732-31-2410

PIN, PISTON

4шт.

|$$11

-1шт.

|$11

OVERSIZE SERVICE PARTS

-1шт.

4

6736-39-3400

BEARING, CONNECTING ROD (0.25MM OVERSIZE)

-2шт.

4

6736-38-3400

BEARING, CONNECTING ROD (0.50MM OVERSIZE)

-2шт.

4

6736-37-3400

BEARING, CONNECTING ROD (0.75MM OVERSIZE)

-2шт.

4

6736-36-3400

BEARING, CONNECTING ROD (1.00MM OVERSIZE)

-2шт.

|$16

6735-39-2210

KIT, ENGINE PISTON (0.50MM OVERSIZE)

4шт.

5

NSS

PISTON, ENGINE

1шт.

6

6736-31-2510

RING, RETAINING

2шт.

7

6732-39-2300

SET, PISTON RING

1шт.

|$20

6735-38-2210

KIT, ENGINE PISTON (1.00MM OVERSIZE)

4шт.

5

NSS

PISTON, ENGINE

1шт.

6

6736-31-2510

RING, RETAINING

2шт.

7

6732-38-2300

SET, PISTON RING

1шт.
