Запчасти Komatsu WA120-3 КЛАПАН УПРАВЛЕНИЯ ТРАНСМИССИЕЙ (/) (ВЕРХНИЙ КЛАПАН) (ДЛЯ -SPEED) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$7

416-15-21113

TRANSMISSION ASS'Y

SN: (154486)-UP

1шт.

|$8

0

TRANSMISSION ASS'Y

SN: ((154486)-00054253)

1шт.

|$9

416-15-21111

TRANSMISSION ASS'Y

SN: 53001-(154485)

1шт.

|$$5

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-68A0.

-1шт.

|$11

416-15-21152

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: (154486)-UP

1шт.

|$12

0

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: ((154486)-00054253)

1шт.

|$13

416-15-21150

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 53001-(154485)

1шт.

|$$9

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-58A0, 59A2, AND F4350-60A0 TO F4350-68A0.

-1шт.

|$15

416-15-15003

CONTROL VALVE ASS'Y

SN: 53001-UP

1шт.

|$$11

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-61A0 AND F4350-62A0.

-1шт.

1

415-15-15210

BODY,VALVE

SN: 53001-UP

1шт.

2

415-15-15671

VALVE,CHECK

SN: 53001-UP

1шт.

3

415-15-15660

PLUG,VALVE

SN: 53001-UP

1шт.

4

04260-01270

BALL

SN: 53001-UP

1шт.

5

419-15-15510

SPRING,CHECK

SN: 53001-UP

1шт.

6

415-15-15430

PLUG

SN: 53001-UP

1шт.

7

415-15-15290

PLUG

SN: 53001-UP

1шт.

8

07002-03034

O-RING (K2)

SN: 53001-UP

1шт.

9

07042-80108

PLUG

SN: 53001-UP

1шт.

10

415-15-15220

GASKET (K2)

SN: 53001-UP

1шт.

11

417-15-15743

BODY,VALVE

SN: 53001-UP

1шт.

12

417-15-15752

VALVE

SN: 53001-UP

2шт.

13

417-15-15760

SPRING

SN: 53001-UP

1шт.

14

07040-13618

PLUG

SN: 53001-UP

1шт.

15

07002-03634

O-RING (K2)

SN: 53001-UP

1шт.

16

415-15-15320

GASKET (K2)

SN: 53001-UP

1шт.
