Артикул
Название
Примечание
Количество
|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$5
714-11-10003
TRANSMISSION ASS'Y
SN: (68511)-UP
1шт.
|$6
714-11-10002
TRANSMISSION ASS'Y
SN: 53001-(68510)
1шт.
|$7
714-11-10043
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: (68511)-UP
1шт.
|$8
714-11-10042
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: 53001-(68510)
1шт.
|$$6
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A1 TO F4350-69A1.
-1шт.
1
714-11-18511
LEVER
SN: 53001-UP
1шт.
2
714-11-18651
LEVER
SN: 53001-UP
1шт.
3
01252-30816
BOLT
SN: 53001-UP
1шт.
4
714-09-16282
WASHER
SN: 53001-UP
1шт.
5
714-11-18522
PISTON,WITH PIN
SN: 53001-UP
1шт.
8
714-11-18630
PLATE
SN: 53001-UP
1шт.
11
421-40-12420
WASHER
SN: 53001-UP
2шт.
13
714-11-19810
SEAL,OIL (K1)
SN: 53001-UP
1шт.
14
714-11-18340
BALL
SN: 53001-UP
6шт.
Выбрано товаров: 21
