Запчасти Komatsu WA120-3 ТРАНСМИССИЯ (ВЫХОДНОЙ ВАЛ) (ДЛЯ -SPEED) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$5

714-11-10003

TRANSMISSION ASS'Y

SN: (68511)-UP

1шт.

|$6

714-11-10002

TRANSMISSION ASS'Y

SN: 53001-(68510)

1шт.

|$7

714-11-10043

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: (68511)-UP

1шт.

|$8

714-11-10042

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 53001-(68510)

1шт.

|$$6

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A1 TO F4350-69A1.

-1шт.

1

714-11-14520

SHAFT,OUTPUT

SN: 53001-UP

1шт.

2

714-11-14620

GEAR, 48 TEETH,OUTPUT

SN: 53001-UP

1шт.

3

04064-06020

RING,SNAP

SN: 53001-UP

1шт.

4

714-11-19360

BEARING

SN: (69310)-UP

1шт.

4

06002-30210

BEARING

SN: 53001-(69309)

1шт.

5

714-11-19360

BEARING

SN: (69310)-UP

1шт.

5

06002-30210

BEARING

SN: 53001-(69309)

1шт.

6

714-11-14911

COVER,GEAR

SN: 53001-UP

1шт.

7

01010-81225

BOLT

SN: 53001-UP

2шт.

8

01643-31232

WASHER

SN: 53001-UP

2шт.

9

714-11-14210

COUPLING,FRONT

SN: 53001-UP

1шт.

10

417-15-13770

HOLDER

SN: 53001-UP

1шт.

11

01011-61610

BOLT

SN: 53001-UP

1шт.

12

417-15-13790

O-RING (K1)

SN: 53001-UP

1шт.

13

07012-50065

SEAL (K1)

SN: (69675)-UP

1шт.

13

417-15-13690

SEAL,OIL (K1)

SN: 53001-(69674)

1шт.

14

07012-50065

SEAL (K1)

SN: (69675)-UP

1шт.

14

417-15-13690

SEAL,OIL (K1)

SN: 53001-(69674)

1шт.

15

417-15-13810

SEAL,DUST (K1)

SN: 53001-UP

1шт.

16

417-15-13810

SEAL,DUST (K1)

SN: 53001-UP

1шт.

17

714-11-18610

HUB,SPLINE

SN: 53001-UP

1шт.

18

714-11-14231

COUPLING,REAR

SN: (170428)-UP

1шт.

18

714-11-14230

COUPLING,REAR

SN: 53001-(170427)

1шт.

19

714-11-14271

SHIM, 0.05MM

SN: 53001-UP

3шт.

19

714-11-14281

SHIM, 0.20MM

SN: 53001-UP

2шт.

19

714-11-14291

SHIM, 0.50MM

SN: 53001-UP

3шт.

19

714-11-14371

SHIM, 0.05MM

SN: 53001-UP

3шт.

19

714-11-14381

SHIM, 0.20MM

SN: 53001-UP

2шт.

19

714-11-14391

SHIM, 0.50MM

SN: 53001-UP

3шт.
