Запчасти Komatsu WA120-3 ТРАНСМИССИЯ (2 И 3 МУФТА) (ДЛЯ -SPEED) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$7

416-15-21113

TRANSMISSION ASS'Y

SN: (154486)-UP

1шт.

|$8

0

TRANSMISSION ASS'Y

SN: ((154486)-00054253)

1шт.

|$9

416-15-21111

TRANSMISSION ASS'Y

SN: 53001-(154485)

1шт.

|$$5

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-68A0.

-1шт.

|$11

416-15-21152

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: (154486)-UP

1шт.

|$12

0

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: ((154486)-00054253)

1шт.

|$13

416-15-21150

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 53001-(154485)

1шт.

|$$9

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-58A0, 59A2, AND F4350-60A0 TO F4350-68A0.

-1шт.

|$16

416-15-13102

CLUTCH ASS'Y,2ND AND 3RD

SN: 53001-UP

1шт.

|$17

416-15-13112

SHAFT ASS'Y

SN: 53001-UP

1шт.

1

0

SHAFT,2ND AND 3RD

SN: 53001-UP

1шт.

2

0

HOUSING

SN: (154696)-UP

1шт.

2

0

HOUSING

SN: 53001-(154695)

1шт.

3

419-15-13191

PISTON,2ND AND 3RD

SN: 53001-UP

2шт.

4

7720-50-2590

DISC

SN: 53001-UP

8шт.

5

714-16-19730

PLATE,SEPARATE

SN: 53001-UP

10шт.

6

56D-15-12710

SPRING,WAVE

SN: (154633)-UP

8шт.

6

0

SPRING,WAVE

SN: 53001-(154632)

8шт.

7

419-15-12281

PLATE,END

SN: 53001-UP

2шт.

8

419-15-12140

RING,SNAP

SN: 53001-UP

2шт.

9

419-15-12580

RING,SEAL (K1)

SN: 53001-UP

2шт.

10

419-15-12210

RING,SEAL (K1)

SN: 53001-UP

2шт.

11

419-15-12680

WASHER,THRUST

SN: 53001-UP

6шт.

12

419-15-12670

BEARING,THRUST

SN: 53001-UP

3шт.

13

419-15-12240

WASHER,THRUST

SN: 53001-UP

2шт.

14

419-15-12250

BEARING,THRUST

SN: 53001-UP

1шт.

15

714-23-19430

BEARING

SN: (54076)-UP

1шт.

15

0

BEARING,NEEDLE

SN: (53893)-(54075)

1шт.

15

0

BEARING,NEEDLE

SN: 53001-(53892)

1шт.

16

419-15-12271

BEARING

SN: (54076)-UP

2шт.

16

0

BEARING

SN: 53001-(54075)

2шт.

17

417-15-13222

GEAR, 39 TEETH,2ND

SN: 53001-UP

1шт.

18

417-15-13231

GEAR, 21 TEETH,3RD

SN: 53001-UP

1шт.

19

417-15-13242

GEAR, 27 TEETH

SN: 53001-UP

1шт.

20

419-15-12330

SPACER

SN: 53001-UP

1шт.

21

06030-06312

BEARING,BALL

SN: 53001-UP

1шт.

22

06030-06210

BEARING

SN: 53001-UP

1шт.

23

419-15-12121

RING,SEAL (K1)

SN: 53001-UP

3шт.
