Запчасти Komatsu WA120-3 ТРАНСМИССИЯ (КОРПУС ТРАНСМИССИИ) (ДЛЯ -SPEED) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$7

416-15-21113

TRANSMISSION ASS'Y

SN: (154486)-UP

1шт.

|$8

0

TRANSMISSION ASS'Y

SN: ((154486)-00054253)

1шт.

|$9

416-15-21111

TRANSMISSION ASS'Y

SN: 53001-(154485)

1шт.

|$$5

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-68A0.

-1шт.

|$11

416-15-21152

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: (154486)-UP

1шт.

|$12

0

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: ((154486)-00054253)

1шт.

|$13

416-15-21150

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 53001-(154485)

1шт.

|$$9

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-58A0, 59A2, AND F4350-60A0 TO F4350-68A0.

-1шт.

|$16

417-15-18103

CASE ASS'Y,TRANSMISSION

SN: 53001-UP

1шт.

1

0

CASE,FRONT

SN: 53001-UP

1шт.

2

0

SHAFT,IDLER

SN: 53001-UP

1шт.

|$19

417-15-18303

CASE ASS'Y,TORQUE CONVERTER

SN: 53001-UP

1шт.

3

0

CASE,REAR

SN: 53001-UP

1шт.

4

0

TUBE,LUBRICATION

SN: 53001-UP

1шт.

5

0

TUBE,FORWARD

SN: 53001-UP

1шт.

6

0

TUBE,REVERSE

SN: 53001-UP

1шт.

7

0

TUBE,T/C INLET

SN: 53001-UP

1шт.

8

0

TUBE,T/C OUTLET

SN: 53001-UP

1шт.

9

0

TUBE,1ST

SN: 53001-UP

1шт.

10

07043-70415

PLUG

SN: 53001-UP

2шт.

11

07043-71019

PLUG

SN: 53001-UP

1шт.

12

04020-01434

PIN,DOWEL

SN: 53001-UP

2шт.

13

01010-81240

BOLT

SN: 53001-UP

5шт.

14

01010-81240

BOLT

SN: 53001-UP

1шт.

15

01010-81235

BOLT

SN: 53001-UP

12шт.

16

01643-31232

WASHER

SN: 53001-UP

5шт.

17

419-15-18131

LIQUID GASKET,(NOT SHOWN) (K1)

SN: 53001-UP

1шт.
