Запчасти Komatsu WA120-3 МАСЛЯНЫЙ ФИЛЬТР ТРАНСМИССИИ (ДЛЯ -SPEED)(№-(9)) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$3

416-15-21111

TRANSMISSION ASS'Y

SN: 53001-(52934)

1шт.

|$$3

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-68A0.

-1шт.

|$5

416-15-21150

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 53001-(52934)

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-58A0, 59A2, AND F4350-60A0 TO F4350-68A0.

-1шт.

|$7

419-15-14800

FILTER ASS'Y

SN: 53001-(52934)

1шт.

1

424-16-11140

ELEMENT

SN: 53001-(52934)

1шт.

|$9

419-15-14880

COVER ASS'Y,HEAD

SN: 53001-(52934)

1шт.

2

0

COVER,HEAD

SN: 53001-(52934)

1шт.

3

0

VALVE

SN: 53001-(52934)

1шт.

4

419-15-14820

CASE

SN: 53001-(52934)

1шт.

5

424-16-11130

O-RING (K3)

SN: 53001-(52934)

1шт.

6

419-15-14830

BOLT,CENTER

SN: 53001-(52934)

1шт.

7

419-15-14850

WASHER

SN: 53001-(52934)

1шт.

8

419-15-14860

O-RING (K3)

SN: 53001-(52934)

1шт.

9

424-16-11190

SPRING

SN: 53001-(52934)

1шт.

10

419-15-14870

GASKET (K3)

SN: 53001-(52934)

1шт.

11

419-15-14840

PLATE

SN: 53001-(52934)

1шт.

12

07040-11209

PLUG

SN: 53001-(52934)

1шт.

13

07002-01223

O-RING (K3)

SN: 53001-(52934)

1шт.
