Запчасти Komatsu WA120-3 ТРАНСМИССИЯ (2 МУФТА)(№-) ТРАНСМИССИЯ

|$0

714-11-10000

TRANSMISSION ASS'Y

SN: 50001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2301 TO 2371.

-1шт.

|$2

714-11-12020

CLUTCH ASS'Y,FORWARD AND 2ND

SN: 50001-UP

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2323 AND 2324.

-1шт.

1

714-11-12660

PISTON,2ND

SN: 50001-UP

1шт.

2

714-08-19210

RING,SEAL

SN: 50001-UP

1шт.

3

714-11-19230

RING,SEAL

SN: 50001-UP

1шт.

4

714-08-19710

DISC

SN: 50001-UP

5шт.

5

714-08-19730

PLATE,SEPARATE

SN: 50001-UP

6шт.

6

714-08-12910

SPRING,WAVE

SN: 50001-UP

5шт.

7

714-08-12610

PLATE,END

SN: 50001-UP

1шт.

8

714-08-19510

RING,SNAP

SN: 50001-UP

1шт.

9

714-11-12440

GEAR, 27-49 TEETH,2ND

SN: 50001-UP

1шт.

10

419-15-12270

BEARING,NEEDLE

SN: 50001-UP

2шт.

11

714-11-19510

WASHER,THRUST

SN: 50001-UP

2шт.

12

714-11-12710

SPACER

SN: 50001-UP

1шт.

13

06040-06310

BEARING

SN: 50001-UP

1шт.
