Запчасти Komatsu WA120-1LC CRANKING МОТОР - 7MT КОМПОНЕНТЫ ДВИГАТЕЛЯ & ЭЛЕКТРИКА

|$0

1249 496 H91

MOTOR ASSEMBLY, CRANKING

1шт.

1

1232 682 H91

FRAME ASSEMBLY, COMMUTATOR END

1шт.

2

1212 115 H1

WICK

1шт.

3

1212 114 H1

BEARING

1шт.

4

NSS

FRAME, COMMUTATOR END

1шт.

|$5

1232 887 H1

BOLT, FRAME MOUNTING

2шт.

5

1250 952 H1

BRUSH

4шт.

|$7

1232 882 H1

SCREW, BRUSH MOUNTING - GROUND

2шт.

|$8

1232 883 H1

SCREW, BRUSH MOUNTING - INSULATED

2шт.

6

1212 124 H1

HOLDER, BRUSH - GROUND

2шт.

7

1232 865 H1

HOLDER, BRUSH - INSULATED

2шт.

8

1212 144 H1

SPRING, BRUSH

2шт.

9

1251 234 H1

SEAL, CENTER BEARING

1шт.

10

1232 889 H1

CONNECTOR - FIELD COIL TO SWITCH

1шт.

|$14

1243 857 H1

SCREW, MOUNTING - TO SOLENOID SWITCH

1шт.

|$15

1244 656 H1

SCREW, MOUNTING - TO FIELD COIL

1шт.

11

1250 954 H1

CONTACT ASSEMBLY, SWITCH

1шт.

12

1251 231 H1

BOOT, SOLENOID SWITCH

1шт.

13

1250 958 H1

SOLENOID SWITCH, CRANKING MOTOR

1шт.

|$19

132 255

SCREW, MOUNTING

2шт.

|$20

120 380

WASHER, LOCK

2шт.

14

1243 855 H1

SPRING, PLUNGER

1шт.

15

1250 959 H1

PLUNGER, LEVER

1шт.

16

1232 878 H1

LEVER, SHIFT

1шт.

17

1232 879 H1

PIN, LEVER

1шт.

18

1232 880 H1

STUD, LEVER

1шт.

|$26

1251 228 H1

NUT

1шт.

|$27

1251 230 H1

WASHER, SEAL

2шт.

19

1250 957 H91

HOUSING ASSEMBLY, DRIVE

1шт.

20

1243 861 H1

PLUG, OIL WICK

1шт.

21

1243 862 H1

WICK, OIL

1шт.

22

1243 859 H1

BUSHING

1шт.

23

NSS

HOUSING, DRIVE

1шт.

24

1232 873 H1

COLLAR, THRUST

1шт.

25

1212 153 H1

RING, RETAINING

1шт.

26

1232 872 H1

COLLAR, STOP

1шт.

27

1243 853 H1

DRIVE, MOTOR

1шт.

28

1212 155 H1

WASHER

1шт.

29

1250 956 H1

PLATE, CENTER BEARING

1шт.

|$39

1251 229 H1

SCREW AND LOCK WASHER, MOUNT PLATE

4шт.

30

1251 232 H1

BUSHING, CENTER BEARING

1шт.

31

1243 860 H1

PIN, DOWEL

1шт.

32

1250 955 H1

ARMATURE

1шт.

33

1243 858 H1

WASHER, BRAKE

1шт.

34

1232 891 H1

GROMMET

1шт.

35

1250 953 H1

COIL, FIELD

1шт.

36

1232 893 H1

SHOE, POLE

4шт.

|$47

1211 150 H1

SCREW, MOUNTING POLE SHOE

4шт.

37

NSS

HOUSING, ARMATURE AND FIELD COIL

1шт.

38

1251 233 H1

GASKET, CENTER BEARING PLATE

1шт.

|$50

1232 866 H91

PACKAGE, CRANKING MOTOR BRUSH SUPPORT

2шт.

39

120 217

WASHER, LOCK

2шт.

40

120 221

SCREW

2шт.

41

1232 892 H1

PIN, BRUSH HOLDER

1шт.

42

1232 867 H1

LEAD, GROUND

1шт.

43

110 633

NUT

2шт.

44

NSS

SUPPORT, BRUSH

1шт.

|$59

-1шт.

|$58

F1 - FOR MOUNTING HARDWARE SEE PG 01-007.

-1шт.

|$60

-1шт.
