Запчасти Komatsu WA120-1LC АНТИОБЛЕДЕНИТЕЛЬ ТРУБЫ РАМА

1

416-942-1730

HOSE, REAR - HEATER TO FLOOR

1шт.

2

416-942-1360

COUPLING, REAR

1шт.

3

01010-50616

BOLT, REAR COUPLING

2шт.

4

01643-30623

WASHER

2шт.

5

417-942-1260

HOSE, BOTTOM - UNDER FLOOR

1шт.

6

416-942-1370

COUPLING, FORWARD

1шт.

7

01010-50616

BOLT, FORWARD COUPLING

2шт.

8

01643-30623

WASHER

2шт.

9

417-942-1250

HOSE, FORWARD - FLOOR TO DEFROSTER DUCT

1шт.

10

416-942-1210

DUCT, DEFROSTER

1шт.

11

416-942-1280

BRACKET, DUCT MOUNTING

1шт.

12

01010-51020

BOLT, DUCT MOUNTING

3шт.

13

01643-31032

WASHER

3шт.

14

205-03-71191

CLIP, BOTTOM HOSE UNDER FLOOR

2шт.

15

565-07-15170

CLIP, FORWARD HOSE TO DUCT

1шт.

16

01010-50816

BOLT, CLIPS AND BOTTOM GUARD

3шт.

17

01643-30823

WASHER

3шт.

18

417-942-1240

PROTECTOR, REAR GUARD

1шт.

19

417-942-1230

GUARD, BOTTOM HOSE

1шт.

20

417-942-1220

GUARD, FORWARD HOSE

1шт.

21

417-942-1210

GUARD, REAR HOSE

1шт.

22

01010-50816

BOLT, FORWARD AND REAR GUARDS

7шт.

23

01643-30823

WASHER

7шт.

24

HEATER ASSEMBLY (SEE PG 05-090)

-29шт.
