Запчасти Komatsu WA120-1LC СИДЕНЬЕ ОПЕРАТОРА ЖЕСТК. РАМА

|$0

417-57-11211

SEAT ASSEMBLY, RIGID TYPE

1шт.

|$1

417-57-11220

SEAT ASSEMBLY

1шт.

1

417-57-11250

CUSHION, BACK

1шт.

2

423-57-11490

BRACKET

1шт.

3

423-57-11380

SCREW, MOUNT BRACKET TO BACK CUSHION

2шт.

4

417-57-11260

CUSHION, SEAT

1шт.

4A

423-57-11650

SPRING

1шт.

5

423-57-11330

BRACKET, RECLINING

1шт.

6

423-57-11380

SCREW, MOUNT RECLINER BRACKET TO BACK AND SEAT

2шт.

7

423-57-11371

COVER, RECLINING BRACKET

1шт.

8

423-57-11160

SCREW, MOUNT COVER

1шт.

9

423-57-11420

BUSHING

1шт.

10

423-57-11430

SCREW, BRACKET TO SEAT CUSHION

1шт.

11

423-57-11440

WASHER

1шт.

12

423-57-11360

LEVER

1шт.

13

423-57-11410

SCREW, MOUNT LEVER

1шт.

14

423-57-11350

SLIDE, LH

1шт.

15

417-57-11270

SLIDE, RH

1шт.

16

423-57-11390

BOLT, SEAT ASSEMBLY TO SLIDES

4шт.

17

417-57-11231

ARM REST ASSEMBLY, LH

1шт.

18

417-57-11241

ARM REST ASSEMBLY, RH

1шт.

19

417-57-11112

SUPPORT, MOUNTING

2шт.

20

01580-10806

NUT, MOUNT SLIDES TO SUPPORTS

4шт.

21

01643-30823

WASHER

4шт.

22

01010-51225

BOLT, MOUNT SUPPORTS TO FLOOR

4шт.

23

01643-31232

WASHER

4шт.
