Запчасти Komatsu WA100M-3 КАБИНА (HANDRAIL) (ДЛЯ SNOW ОТВАЛ)(№-) OPERATIORS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$3

415-56-22444

CAB ASS'Y,(FOR SNOW BLADE)

SN: 12062-UP

1шт.

|$4

0

CAB ASS'Y,(FOR SNOW BLADE)

SN: 12023-12061

1шт.

|$5

415-56-22442

CAB ASS'Y,(FOR SNOW BLADE)

SN: 12001-12022

1шт.

|$6

415-56-22441

CAB ASS'Y,(FOR SNOW BLADE)

SN: 11546-12000

1шт.

|$7

415-56-22440

CAB ASS'Y,(FOR SNOW BLADE)

SN: 11501-11545

1шт.

|$8

415-56-22454

CAB ASS'Y,(FOR SNOW BLADE + RADIO)

SN: 12062-UP

1шт.

|$9

0

CAB ASS'Y,(FOR SNOW BLADE + RADIO)

SN: 12023-12061

1шт.

|$10

415-56-22452

CAB ASS'Y,(FOR SNOW BLADE + RADIO)

SN: 12001-12022

1шт.

|$11

415-56-22451

CAB ASS'Y,(FOR SNOW BLADE + RADIO)

SN: 11546-12000

1шт.

|$12

415-56-22450

CAB ASS'Y,(FOR SNOW BLADE + RADIO)

SN: 11501-12000

1шт.

|$13

415-56-21503

CAB ASS'Y,(FOR SNOW BLADE + RADIO + A/C)

SN: 12062-UP

1шт.

|$14

0

CAB ASS'Y,(FOR SNOW BLADE + RADIO + A/C)

SN: 12023-12061

1шт.

|$15

415-56-21501

CAB ASS'Y,(FOR SNOW BLADE + RADIO + A/C)

SN: 12001-12022

1шт.

|$16

415-56-21500

CAB ASS'Y,(FOR SNOW BLADE + RADIO + A/C)

SN: 11501-12000

1шт.

|$$15

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01B5 TO K0210-18B6.

-1шт.

1

415-56-21510

HAND RAIL,L.H.

SN: 11501-UP

1шт.

2

415-56-21520

HAND RAIL,R.H.

SN: 11501-UP

1шт.

3

01435-01025

BOLT

SN: 11501-UP

8шт.

4

363-54-31450

CAP

SN: 11501-UP

8шт.

5

09690-B0280

PLATE, MARK

SN: 11501-UP

2шт.

6

421-56-21720

CAP

SN: 11501-UP

4шт.

7

418-923-2890

PLATE, INSTRUCTION,(WITHOUT AIR CONDITIONER)

SN: 12001-UP

1шт.

8

416-54-26190

SEAL

SN: 12023-UP

1шт.
