Запчасти Komatsu WA100-3A-SN ТРАНСМИССИЯ (1 МУФТА) ГИДРОТРАНСФОРМАТОР И ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

416-15-21012

TRANSMISSION ASS'Y

SN: (52935)-UP

1шт.

|1

416-15-21011

TRANSMISSION ASS'Y

SN: (51195)-(52934)

1шт.

|1

416-15-21010

TRANSMISSION ASS'Y

SN: 53001-(51194)

1шт.

|$$5

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.

-1шт.

|1

416-15-12502

CLUTCH ASS'Y,1ST

SN: 53001-UP

1шт.

|1

416-15-12512

SHAFT ASS'Y

SN: 53001-UP

1шт.

1

0

SHAFT

SN: 53001-UP

1шт.

2

419-15-12750

ORIFICE

SN: 53001-UP

1шт.

3

0

HOUSING

SN: 53001-UP

1шт.

4

0

SPACER

SN: 53001-UP

1шт.

5

7720-50-2590

DISC

SN: 53001-UP

4шт.

6

714-16-19730

PLATE,SEPARATE

SN: 53001-UP

5шт.

7

419-15-12133

SPRING,WAVE

SN: 53001-UP

4шт.

8

419-15-12281

PLATE,END

SN: 53001-UP

1шт.

9

419-15-12140

RING,SNAP

SN: 53001-UP

1шт.

10

419-15-12580

RING,SEAL (K1)

SN: 53001-UP

1шт.

11

419-15-12210

RING,SEAL (K1)

SN: 53001-UP

1шт.

12

714-08-19570

WASHER,THRUST

SN: 53001-UP

1шт.

13

714-08-19560

WASHER,THRUST

SN: 53001-UP

1шт.

14

714-23-19410

BEARING,NEEDLE

SN: (53135)-UP

2шт.

|14

0

BEARING,NEEDLE

SN: 53001-(53134)

2шт.

15

419-15-13191

PISTON

SN: 53001-UP

1шт.

16

417-15-12670

COLLAR

SN: 53001-UP

1шт.

17

417-15-12652

GEAR¤ 21 TEETH,1ST

SN: 53001-UP

1шт.

18

417-15-12663

GEAR¤ 32 TEETH

SN: 53001-UP

1шт.

19

417-15-12850

BEARING,BALL

SN: 53001-UP

1шт.

20

06030-06210

BEARING

SN: 53001-UP

1шт.

21

419-15-12121

RING,SEAL (K1)

SN: 53001-UP

2шт.
