Запчасти Komatsu WA100-3A-S ТРАНСМИССИЯ (3 МУФТА)(№-) ГИДРОТРАНСФОРМАТОР И ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

416-15-21010

TRANSMISSION ASS'Y

SN: 50001-UP

1шт.

|$$3

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2201 TO 2271.

-1шт.

|1

416-15-13102

CLUTCH ASS'Y,2ND AND 3RD

SN: 50001-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2224 AND 2225.

-1шт.

1

419-15-12210

RING,SEAL (K1)

SN: 50001-UP

1шт.

2

419-15-13191

PISTON,3RD

SN: 50001-UP

1шт.

3

419-15-12580

RING,SEAL (K1)

SN: 50001-UP

1шт.

4

7720-50-2590

DISC

SN: 50001-UP

3шт.

|4

0

DISC

SN: (50001-.)

3шт.

5

714-16-19730

PLATE,SEPARATE

SN: (50371)-UP

4шт.

|5

419-15-12310

PLATE,SEPARATE

SN: 50001-(50370)

4шт.

6

419-15-12133

SPRING,WAVE

SN: 50001-UP

3шт.

7

419-15-12281

PLATE,END

SN: .-UP

1шт.

|7

0

PLATE,END

SN: 50001-.

1шт.

8

419-15-12140

RING,SNAP

SN: 50001-UP

1шт.

9

419-15-12680

WASHER,THRUST

SN: 50001-UP

2шт.

10

419-15-12670

BEARING,THRUST

SN: 50001-UP

1шт.

11

417-15-13231

GEAR¤ 21 TEETH,3RD

SN: 50001-UP

1шт.

12

419-15-12270

BEARING

SN: 50001-UP

2шт.

13

419-15-12240

WASHER,THRUST

SN: 50001-UP

2шт.

14

419-15-12250

BEARING,THRUST

SN: 50001-UP

1шт.

15

419-15-12330

SPACER

SN: 50001-UP

1шт.

16

06030-06210

BEARING

SN: 50001-UP

1шт.
