Артикул
Название
Примечание
Количество
|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|1
416-15-21010
TRANSMISSION ASS'Y
SN: 50001-UP
1шт.
|$$3
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2201 TO 2271.
-1шт.
|1
416-15-12101
CLUTCH ASS'Y,FORWARD AND REVERSE
SN: 50001-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2221 AND 2222.
-1шт.
2
419-15-12221
PISTON,REVERSE
SN: 50001-UP
1шт.
7
419-15-12281
PLATE,END
SN: .-UP
1шт.
|7
0
PLATE,END
SN: 50001-.
1шт.
9
419-15-12240
WASHER,THRUST
SN: 50001-UP
4шт.
10
419-15-12250
BEARING,THRUST
SN: 50001-UP
2шт.
Выбрано товаров: 22
