Запчасти Komatsu WA100-3A КОВШ КАТАЛОГИ ЗЧ

|$$1

1.2M3 BUCKET

-1шт.

|$$2

1.3M3 BUCKET{(WITH BOLT ON CUTTING EDGE)}

-1шт.

1

416-70-22110

BUCKET

SN: 50001-UP

1шт.

2

416-70-22120

PLATE (WELDED)

SN: 50001-UP

2шт.

3

416-70-12121

EDGE (WELDED)

SN: 50001-UP

1шт.

4

416-70-12A51

PLATE (WELDED)

SN: 50001-UP

2шт.

5

416-70-12B22

PLATE (WELDED)

SN: 50001-UP

2шт.

|$$8

EXCAVATING BUCKET

-1шт.

|$$9

1.0M3 BUCKET

-1шт.

|$$10

1.1M3 BUCKET{(WITH BOLT ON CUTTING EDGE)}

-1шт.

1

416-806-2110

BUCKET

SN: 50001-UP

1шт.

2

416-806-2120

PLATE (WELDED)

SN: 50001-UP

2шт.

3

416-70-12121

EDGE (WELDED)

SN: 50001-UP

1шт.

4

416-806-2A50

PLATE (WELDED)

SN: 50001-UP

2шт.

5

416-806-1A40

PLATE (WELDED)

SN: 50001-UP

2шт.

|$$16

LIGHT MATERIAL{(FOR COUPLER BUCKET)}

-1шт.

|$$17

1.0M3 BUCKET

-1шт.

|$$18

1.1M3 BUCKET{(WITH BOLT ON CUTTING EDGE)}

-1шт.

6

416-840-1101

BUCKET

SN: 50001-UP

1шт.

7

416-70-12132

PLATE (WELDED)

SN: 50001-UP

2шт.

8

416-70-12121

EDGE (WELDED)

SN: 50001-UP

1шт.

9

417-70-12141

PLATE,L.H. (WELDED)

SN: 50001-UP

1шт.

10

417-70-12151

PLATE,R.H. (WELDED)

SN: 50001-UP

1шт.
