Запчасти Komatsu WA100-3-X МАРКИРОВКА (С КАБИНОЙ) (ЯПОН.)(№-) МАРКИРОВКА¤ ИНСТРУМЕНТ И РЕМКОМПЛЕКТЫ

|1

417-93-21110

PLATE KIT

SN: 60001-UP

1шт.

1

0

PLATE¤ SAFETY,KEEP OUT

SN: 60001-UP

2шт.

2

0

PLATE¤ SAFETY,SAFETY BAR

SN: 60001-UP

1шт.

3

0

PLATE¤ INSTRUCTION,FUEL

SN: 60001-UP

1шт.

4

0

PLATE¤ SAFETY,RADIATOR CAP

SN: 60001-UP

1шт.

5

0

PLATE¤ INSTRUCTION,ENGINE OIL

SN: 60001-UP

1шт.

6

0

PLATE¤ SAFETY,BRAKE OIL

SN: 60001-UP

1шт.

7

0

PLATE¤ SAFETY,HYDRAULIC TANK CAP

SN: 60001-UP

1шт.

8

0

PLATE¤ SAFETY,BATTERY CABLE

SN: 60001-UP

1шт.

|9

417-93-21120

PLATE KIT

SN: 60001-UP

1шт.

9

0

PLATE¤ CAUTION,TRAVEL

SN: 60001-UP

1шт.

10

0

PLATE¤ OPERATING,STARTING SWITCH

SN: 60001-UP

1шт.

|10

0

PLATE¤ OPERATING,STARTING SWITCH

SN: 60001-UP

1шт.

11

0

PLATE¤ NAME,FUSE

SN: 60001-UP

1шт.

|11

0

PLATE¤ NAME,FUSE

SN: 60001-UP

1шт.

12

0

PLATE¤ SAFETY,BEFORE OPERATING

SN: 60001-UP

1шт.

13

0

PLATE¤ SAFETY,BRAKE PEDAL

SN: 60001-UP

1шт.

14

0

PLATE¤ INSTRUCTION,STEERING HOSE

SN: 60001-UP

1шт.

15

0

PLATE¤ SAFETY,WORK EQUIPMENT LEVER LOCK

SN: 60001-UP

1шт.

16

0

PLATE¤ SAFETY,INSPECTION

SN: 60001-UP

1шт.

17

0

PLATE¤ OPERATING,WORK EQUIPMENT LEVER

SN: 60001-UP

1шт.

18

0

PLATE¤ OPERATING,LOCK LEVER

SN: 60001-UP

1шт.

19

0

PLATE¤ CAUTION,PARKING BRAKE

SN: 60001-UP

1шт.

20

416-93-21130

PLATE¤ MARK,WA100

SN: 60001-UP

2шт.

21

417-93-21220

PLATE¤ MARK,AVANCE LOADER

SN: 60001-UP

2шт.

22

09690-B0224

PLATE¤ MARK,KOMATSU

SN: 60001-UP

2шт.

23

417-93-21140

PLATE¤ MARK,KOMATSU

SN: 60001-UP

1шт.

24

417-93-21150

PLATE¤ STRIPE,L.H.

SN: 60001-UP

1шт.

25

417-93-21160

PLATE¤ STRIPE,R.H.

SN: 60001-UP

1шт.

26

416-93-21110

CHART¤ OIL

SN: 60001-UP

1шт.

27

09602-01635

PLATE¤ NAME,(LIMITED SUPPLY)

SN: 60001-UP

1шт.

|27

04418-13060

SCREW

SN: 60001-UP

4шт.

28

417-93-21190

PLATE¤ NAME,INSTRUMENT PANEL

SN: 60001-UP

1шт.

29

416-93-21120

PLATE¤ DATA

SN: 60001-UP

1шт.

30

417-54-24550

PLATE¤ CAUTION,(WITH REAR FENDER) (OP)

SN: 60001-UP

2шт.

31

417-56-21290

PLATE¤ OPERATING,DOOR LOCK

SN: 60001-UP

2шт.

32

09685-00001

PLATE¤ OPERATING,LOCK LEVER(WITH 5-SPOOL VALVE)

SN: 60001-UP

1шт.
