Запчасти Komatsu WA100-3-HW ТРАНСМИССИЯ (РЕВЕРС И 1 МУФТА) ГИДРОТРАНСФОРМАТОР И ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

714-15-10004

TRANSMISSION ASS'Y

SN: (54021)-UP

1шт.

|1

714-15-10003

TRANSMISSION ASS'Y

SN: (53782)-(54020)

1шт.

|1

714-15-10002

TRANSMISSION ASS'Y

SN: (53682)-(53681)

1шт.

|1

714-15-10001

TRANSMISSION ASS'Y

SN: (53412)-(53681)

1шт.

|1

714-15-10000

TRANSMISSION ASS'Y

SN: 63001-(53411)

1шт.

|$$7

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A1 TO F4350-67A1.

-1шт.

|1

714-15-12010

CLUTCH ASS'Y,REVERSE AND 1ST

SN: 63001-UP

1шт.

|1

714-11-12260

SHAFT ASS'Y

SN: 63001-UP

1шт.

1

0

SHAFT

SN: 63001-UP

1шт.

2

0

HOUSING ASS'Y

SN: 63001-UP

1шт.

3

714-11-12650

PISTON,REVERSE

SN: 63001-UP

1шт.

4

714-11-12660

PISTON,1ST

SN: 63001-UP

1шт.

5

714-08-19710

DISC

SN: 63001-UP

13шт.

6

714-08-19730

PLATE,SEPARATE

SN: 63001-UP

15шт.

7

714-08-12910

SPRING,WAVE

SN: 63001-UP

13шт.

8

714-08-12610

PLATE,END

SN: 63001-UP

2шт.

9

714-08-19510

RING,SNAP

SN: 63001-UP

2шт.

10

714-08-19210

RING,SEAL

SN: 63001-UP

2шт.

11

714-11-19240

RING,SEAL

SN: 63001-UP

1шт.

12

714-11-19230

RING,SEAL

SN: 63001-UP

1шт.

13

714-11-19510

WASHER,THRUST

SN: 63001-UP

4шт.

14

714-11-12710

SPACER

SN: 63001-UP

2шт.

15

419-15-12271

BEARING,NEEDLE

SN: (54115)-UP

2шт.

|15

0

BEARING,NEEDLE

SN: 63001-(54114)

2шт.

16

714-11-12410

GEAR¤ 45 TEETH,REVERSE

SN: 63001-UP

1шт.

17

714-11-12420

GEAR¤ 29 TEETH,1ST

SN: 63001-UP

1шт.

18

06040-06210

BEARING

SN: 63001-UP

2шт.

19

419-15-12122

RING,SEAL

SN: 63001-UP

3шт.
