77C/D S/N 77501413 - Up
/
ГИДРАВЛИКА
/

ЦИЛИНДР КОВША, EXECUTION II

Запчасти Komatsu 77C ЦИЛИНДР КОВША, EXECUTION II ГИДРАВЛИКА

Схема запчастей Komatsu 77C - ЦИЛИНДР КОВША, EXECUTION II ГИДРАВЛИКА
14
1
2
28
29
22
23
24
26
3
17
27
20
18
25
20
30
4
16
19
21
11
10
5
9
4
7
30
8
7
15
6
13
12
31

№

Артикул

Название

Примечание

Количество

1

4005067M91

BUCKET CYLINDER

EnglischBem: LEFT

1шт.

2

4005068M91

BUCKET CYLINDER

EnglischBem: RIGHT

1шт.

3

4912053M91

CYLINDER HOUSING

EnglischBem: NOTE: Pos. (3) included in Pos. (1) and (2) Kit

1шт.

4

4911357M1

BUSHING

EnglischBem: NOTE: Pos. (4) included in Pos. (1) and (2) Kit

2шт.

5

4911355M1

RING

EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (2) Kit

1шт.

6

4912054M91

CYLINDER ROD

EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (2) Kit

1шт.

7

4911356M1

BUSHING

EnglischBem: NOTE: Pos. (7) included in Pos. (1) and (2) Kit

2шт.

8

4911354M1

RING

EnglischBem: NOTE: Pos. (8) included in Pos. (1) and (2) Kit

1шт.

9

4911358M1

GUIDE BUSH

EnglischBem: NOTE: Pos. (9) included in Pos. (1) and (2) Kit

1шт.

10

4911344M1

STRIPPER

EnglischBem: BELONGS TO SEAL KIT 4911 328 M91 NOTE: Pos. (10) included in Pos

1шт.

11

4911350M1

SNAP RING

EnglischBem: NOTE: Pos. (11) included in Pos. (1) and (2) Kit

1шт.

12

4911343M1

SEAL

EnglischBem: BELONGS TO SEAL KIT 4911 328 M91 NOTE: Pos. (12) included in Pos

1шт.

13

4911351M1

PILOT

EnglischBem: NOTE: Pos. (13) included in Pos. (1) and (2) Kit

1шт.

14

4911347M1

BACK-UP RING

EnglischBem: BELONGS TO SEAL KIT 4911 328 M91 NOTE: Pos. (14) included in Pos

1шт.

15

4911349M1

O-RING

EnglischBem: BELONGS TO SEAL KIT 4911 328 M91 NOTE: Pos. (15) included in Pos

1шт.

16

NOT USED

DeutschDesc: NICHT VERWENDET

-1шт.

17

4911331M1

O-RING

EnglischBem: BELONGS TO SEAL KIT 4911 328 M91 NOTE: Pos. (17) included in Pos

1шт.

18

4911716M1

GASKET

EnglischBem: BELONGS TO SEAL KIT 4911 328 M91 NOTE: Pos. (18) included in Pos

1шт.

19

4911329M1

PISTON

EnglischBem: NOTE: Pos. (19) included in Pos. (1) and (2) Kit

1шт.

20

4912011M1

PILOT

EnglischBem: BELONGS TO SEAL KIT 4911 328 M91 NOTE: Pos. (20) included in Pos

2шт.

21

1607699M1

NUT

EnglischBem: NOTE: Pos. (21) included in Pos. (1) and (2) Kit

1шт.

22

4912055M91

PIPE

EnglischBem: RIGHT

1шт.

23

4912057M91

PIPE

EnglischBem: LEFT

1шт.

24

4911332M1

O-RING

EnglischBem: NOTE: Pos. (24) included in Pos. (1) and (2) Kit

1шт.

25

4911348M1

O-RING

EnglischBem: NOTE: Pos. (25) included in Pos. (1) and (2) Kit

1шт.

26

339814X1

SCREW

EnglischBem: NOTE: Pos. (26) included in Pos. (1) and (2) Kit

4шт.

27

1443790X1

SPRING WASHER

EnglischBem: NOTE: Pos. (27) included in Pos. (1) and (2) Kit

4шт.

28

1441436X1

SCREW

EnglischBem: NOTE: Pos. (28) included in Pos. (1) and (2) Kit

4шт.

29

391241X1

SPRING WASHER

EnglischBem: NOTE: Pos. (29) included in Pos. (1) and (2) Kit

4шт.

30

339608X1

LUBRICATION NIPPLE

EnglischBem: NOTE: Pos. (30) included in Pos. (1) and (2) Kit

2шт.

31

4911328M91

GASKET KIT

DeutschDesc: DICHTUNGSSATZ

1шт.
