Запчасти Komatsu 77C ЦИЛИНДР КОВША, EXECUTION I ГИДРАВЛИКА
№
Артикул
Название
Примечание
Количество
1
1608147M91
BUCKET CYLINDER
EnglischBem: REPAIRS AND REPLACES 1608 145 M91 RIGHT
1шт.
1A
1608146M91
BUCKET CYLINDER
EnglischBem: REPAIRS AND REPLACES 1608 145 M91 LEFT
1шт.
2
1609573M91
HOUSING
EnglischBem: NOTE: Pos. (2) included in Pos. (1) and (1A) Kit
1шт.
3
HOUSING
EnglischBem: ORDER 1609 573 M91
1шт.
4
1608878M1
BUSHING
DeutschDesc: BUCHSE
2шт.
5
1608879M1
RING
DeutschDesc: RING
1шт.
6
1608985M91
CYLINDER ROD
EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (1A) Kit
1шт.
7
CYLINDER ROD
EnglischBem: ORDER 1608 985 M91
1шт.
8
1608895M1
BUSHING
DeutschDesc: BUCHSE
2шт.
9
1608896M1
RING
DeutschDesc: RING
1шт.
10
1609570M1
BUSHING
EnglischBem: NOTE: Pos. (10) included in Pos. (1) and (1A) Kit
1шт.
11
1607859M1
STRIPPER
EnglischBem: BELONGS TO SEAL KIT 1609 572 M92 NOTE: Pos. (11) included in Pos
1шт.
12
1607861M1
SEAL
EnglischBem: BELONGS TO SEAL KIT 1609 572 M92 NOTE: Pos. (12) included in Pos
1шт.
13
1608629M1
TAB WASHER
EnglischBem: NOTE: Pos. (13) included in Pos. (1) and (1A) Kit
1шт.
14
1089309M1
BACK-UP RING
EnglischBem: BELONGS TO SEAL KIT 1609 572 M92 NOTE: Pos. (14) included in Pos
1шт.
15
359209X1
O-RING
EnglischBem: BELONGS TO SEAL KIT 1609 572 M92 NOTE: Pos. (15) included in Pos
1шт.
16
1608834M1
BEARING
EnglischBem: BELONGS TO SEAL KIT 1609 572 M92 NOTE: Pos. (16) included in Pos
1шт.
17
1609571M2
PISTON
EnglischBem: NOTE: Pos. (17) included in Pos. (1) and (1A) Kit
1шт.
18
359193X1
O-RING
EnglischBem: BELONGS TO SEAL KIT 1609 572 M92 NOTE: Pos. (18) included in Pos
1шт.
19
1606818M1
RING
EnglischBem: BELONGS TO SEAL KIT 1609 572 M92 NOTE: Pos. (19) included in Pos
2шт.
20
1607702M1
BACK-UP RING
EnglischBem: BELONGS TO SEAL KIT 1609 572 M92 NOTE: Pos. (20) included in Pos
2шт.
21
359208X1
O-RING
EnglischBem: BELONGS TO SEAL KIT 1609 572 M92 NOTE: Pos. (21) included in Pos
1шт.
22
1089290M1
SEAL
EnglischBem: BELONGS TO SEAL KIT 1609 572 M92 NOTE: Pos. (22) included in Pos
1шт.
23
1607699M1
NUT
EnglischBem: NOTE: Pos. (23) included in Pos. (1) and (1A) Kit
1шт.
24
339608X1
LUBRICATION NIPPLE
EnglischBem: NOTE: Pos. (24) included in Pos. (1) and (1A) Kit
2шт.
25
1608991M91
PIPE
EnglischBem: RIGHT
1шт.
26
1608992M91
PIPE
EnglischBem: LEFT
1шт.
27
359305X1
O-RING
EnglischBem: RIGHT NOTE: Pos. (27) included in Pos. (1) and (1A) Kit
2шт.
28
359307X1
O-RING
EnglischBem: BELONGS TO SEAL KIT 1609 572 M92 NOTE: Pos. (28) included in Pos
2шт.
29
1441436X1
SCREW
EnglischBem: NOTE: Pos. (29) included in Pos. (1) and (1A) Kit
8шт.
30
391241X1
SPRING WASHER
EnglischBem: NOTE: Pos. (30) included in Pos. (1) and (1A) Kit
8шт.
31
339814X1
SCREW
EnglischBem: NOTE: Pos. (31) included in Pos. (1) and (1A) Kit
8шт.
32
339376X1
SPRING WASHER
EnglischBem: NOTE: Pos. (32) included in Pos. (1) and (1A) Kit
8шт.
33
1609572M92
GASKET KIT
DeutschDesc: DICHTUNGSSATZ
1шт.
Выбрано товаров: 34
