Запчасти Komatsu 77C TWIN НАСОС ГИДРАВЛИКА

1

2949297M91

TANDEM PUMP

DeutschDesc: TANDEMPUMPE

1шт.

2

2970946M91

TANDEM PUMP

DeutschDesc: TANDEMPUMPE

1шт.

3

2961441M91

PUMP

DeutschDesc: PUMPE

1шт.

4

2962198M91

PUMP

DeutschDesc: PUMPE

1шт.

5

2949224M1

SLEEVE

EnglischBem: NOTE: Pos. (5) included in Pos. (3) and (4) Kit

1шт.

6

2949225M1

DISC

EnglischBem: NOTE: Pos. (6) included in Pos. (3) and (4) Kit

1шт.

7

2951886M1

GRUB SCREW

EnglischBem: NOTE: Pos. (7) included in Pos. (3) and (4) Kit

4шт.

8

2951887M1

NUT

EnglischBem: NOTE: Pos. (8) included in Pos. (3) and (4) Kit

4шт.

9

2951884M1

SCREW

EnglischBem: NOTE: Pos. (9) included in Pos. (3) and (4) Kit

4шт.

10

2962197M91

PUMP

DeutschDesc: PUMPE

1шт.

11

2961777M91

PUMP

DeutschDesc: PUMPE

1шт.

12

2949226M1

COUPLING/CLUTCH

EnglischBem: NOTE: Pos. (12) included in Pos. (10) and (11) Kit

1шт.

13

2949225M1

DISC

EnglischBem: NOTE: Pos. (13) included in Pos. (10) and (11) Kit

1шт.

14

2951884M1

SCREW

EnglischBem: NOTE: Pos. (14) included in Pos. (10) and (11) Kit

4шт.

15

2951881M1

GASKET KIT

EnglischBem: REPAIRS AND REPLACES 2949 300 M91 TO BE USED FOR PUMP 2961 441 M

1шт.

16

2949299M91

GASKET KIT

EnglischBem: REPAIRS AND REPLACES 2949 301 M91 TO BE USED FOR PUMP 2962 197 M

1шт.

17

3236185M1

GASKET

DeutschDesc: DICHTUNG

2шт.
