Запчасти Komatsu 77C ПЕРЕДНИЙ МОСТ, ТОРМОЗ., DISC ТОРМОЗ. СИСТЕМАУПРАВЛЕНИЯ ПОВОРОТОМ, ПЕРЕДНИЙ МОСТ, ТОРМОЗ. СИСТЕМА

1

3236281M91

BRAKE

EnglischBem: FOR LEFT FRONT

1шт.

2

3236280M91

BRAKE

EnglischBem: FOR RIGHT FRONT

1шт.

3

BRAKE SADDLE

EnglischBem: ORDER 3236 281 M91

1шт.

4

BRAKE SADDLE

EnglischBem: ORDER 3236 280 M91

1шт.

5

3235406M91

BRAKE LINING

EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (2) Kit

8шт.

6

3235199M1

COVER

EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (2) Kit

2шт.

7

339282X1

SCREW

EnglischBem: NOTE: Pos. (7) included in Pos. (1) and (2) Kit

16шт.

7A

390734X1

PLAIN WASHER

EnglischBem: NOTE: Pos. (7A) included in Pos. (1) and (2) Kit

16шт.

8

3230096M1

SLIDE

EnglischBem: NOTE: Pos. (8) included in Pos. (1) and (2) Kit

4шт.

8A

3230027M1

SPRING

EnglischBem: NOTE: Pos. (8A) included in Pos. (1) and (2) Kit

4шт.

9

3236288M91

PISTON KIT

EnglischBem: NOTE: Pos. (9) included in Pos. (1) and (2) Kit

4шт.

9A

CAP

EnglischBem: BELONGS TO SEAL KIT 3236 289 M91 SI 2500/85-7 NOTE: Pos. (9A) in

8шт.

10

STRIPPER

EnglischBem: BELONGS TO SEAL KIT 3236 289 M91 NOTE: Pos. (10) included in Pos

8шт.

11

SEAL

EnglischBem: BELONGS TO SEAL KIT 3236 289 M91 NOTE: Pos. (11) included in Pos

8шт.

12

3236286M1

COVER

EnglischBem: NOTE: Pos. (12) included in Pos. (1) and (2) Kit

2шт.

12A

3236285M1

COVER

EnglischBem: NOTE: Pos. (12A) included in Pos. (1) and (2) Kit

2шт.

13

O-RING

EnglischBem: BELONGS TO SEAL KIT 3236 289 M91 NOTE: Pos. (13) included in Pos

4шт.

14

3075672M1

SCREW

EnglischBem: NOTE: Pos. (14) included in Pos. (1) and (2) Kit

24шт.

15

1443790X1

SPRING WASHER

EnglischBem: NOTE: Pos. (15) included in Pos. (1) and (2) Kit

24шт.

16

2950552M1

VALVE

EnglischBem: NOTE: Pos. (16) included in Pos. (1) and (2) Kit

6шт.

17

VALVE

EnglischBem: ORDER 2950 552 M1

6шт.

18

3076886M1

DUST CAP

DeutschDesc: STAUBKAPPE

6шт.

18A

3235194M1

COVER

EnglischBem: NOTE: Pos. (18A) included in Pos. (1) and (2) Kit

2шт.

19

3236280M91

BRAKE

EnglischBem: FOR LEFT REAR

1шт.

20

3236281M91

BRAKE

EnglischBem: FOR RIGHT REAR

1шт.

21

BRAKE SADDLE

EnglischBem: ORDER 3236 280 M91

1шт.

22

BRAKE SADDLE

EnglischBem: ORDER 3236 281 M91

1шт.

23

3235406M91

BRAKE LINING

EnglischBem: NOTE: Pos. (23) included in Pos. (19) and (20) Kit

8шт.

24

3235199M1

COVER

EnglischBem: NOTE: Pos. (24) included in Pos. (19) and (20) Kit

2шт.

25

3230096M1

SLIDE

EnglischBem: NOTE: Pos. (25) included in Pos. (19) and (20) Kit

4шт.

25A

3230027M1

SPRING

EnglischBem: NOTE: Pos. (25A) included in Pos. (19) and (20) Kit

4шт.

26

3235194M1

COVER

EnglischBem: NOTE: Pos. (26) included in Pos. (19) and (20) Kit

1шт.

27

339282X1

SCREW

EnglischBem: NOTE: Pos. (27) included in Pos. (19) and (20) Kit

16шт.

27A

390734X1

PLAIN WASHER

EnglischBem: NOTE: Pos. (27A) included in Pos. (19) and (20) Kit

16шт.

28

3236288M91

PISTON KIT

EnglischBem: NOTE: Pos. (28) included in Pos. (19) and (20) Kit

4шт.

28A

CAP

EnglischBem: BELONGS TO SEAL KIT 3236 289 M91 SI 2500/85-7 Pos. (28A) include

8шт.

29

STRIPPER

EnglischBem: BELONGS TO SEAL KIT 3236 289 M91 Pos. (29) included in Pos. (19)

8шт.

30

SEAL

EnglischBem: BELONGS TO SEAL KIT 3236 289 M91 Pos. (30) included in Pos. (19)

8шт.

31

3236286M1

COVER

EnglischBem: NOTE: Pos. (31) included in Pos. (19) and (20) Kit

2шт.

31A

3236285M1

COVER

EnglischBem: NOTE: Pos. (31A) included in Pos. (19) and (20) Kit

2шт.

32

O-RING

EnglischBem: BELONGS TO SEAL KIT 3236 289 M91 Pos. (32) included in Pos. (19)

4шт.

33

3075672M1

SCREW

EnglischBem: NOTE: Pos. (33) included in Pos. (19) and (20) Kit

24шт.

34

1443790X1

SPRING WASHER

EnglischBem: NOTE: Pos. (34) included in Pos. (19) and (20) Kit

24шт.

35

2950552M1

VALVE

EnglischBem: NOTE: Pos. (35) included in Pos. (19) and (20) Kit

6шт.

36

VALVE

EnglischBem: ORDER 2950 552 M1

6шт.

37

3076886M1

DUST CAP

DeutschDesc: STAUBKAPPE

6шт.

38

3236289M91

GASKET KIT

DeutschDesc: DICHTUNGSSATZ

-26шт.
