Запчасти Komatsu 77C ПЕРЕДНИЙ МОСТ, ТОРМОЗ. СИСТЕМАУПРАВЛЕНИЯ ПОВОРОТОМ, ПЕРЕДНИЙ МОСТ, ТОРМОЗ. СИСТЕМА

1

3236000M91

BRAKE

EnglischBem: LEFT

1шт.

2

3236001M91

BRAKE

EnglischBem: RIGHT

1шт.

3

3071018M1

BRAKE PLATE

EnglischBem: NOTE: Pos. (3) included in Pos. (1) and (2) Kit

2шт.

4

3002485X1

O-RING

EnglischBem: REPAIRS AND REPLACES 2964 843 X1 NOTE: Pos. (4) included in Pos.

2шт.

5

3071032M1

SCREW

EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (2) Kit

2шт.

6

3006122X1

SPRING PLATE

EnglischBem: REPAIRS AND REPLACES 3004 804 X1 NOTE: Pos. (6) included in Pos.

2шт.

7

3071033M1

GASKET

EnglischBem: NOTE: Pos. (7) included in Pos. (1) and (2) Kit

2шт.

8

3071042M1

DISC

EnglischBem: NOTE: Pos. (8) included in Pos. (1) and (2) Kit

2шт.

9

3071019M1

GASKET

EnglischBem: NOTE: Pos. (9) included in Pos. (1) and (2) Kit

4шт.

10

2944126M1

PLUG

EnglischBem: NOTE: Pos. (10) included in Pos. (1) and (2) Kit

4шт.

11

3085542M1

BRAKE CARRIER

EnglischBem: NOTE: Pos. (11) included in Pos. (1) and (2) Kit

2шт.

12

3071020M1

BUSHING

EnglischBem: NOTE: Pos. (12) included in Pos. (1) and (2) Kit

2шт.

13

3006136X1

SPRING WASHER

EnglischBem: NOTE: Pos. (13) included in Pos. (1) and (2) Kit

4шт.

14

339018X1

SCREW

EnglischBem: NOTE: Pos. (14) included in Pos. (1) and (2) Kit

4шт.

15

3071021M1

BUSHING

EnglischBem: NOTE: Pos. (15) included in Pos. (1) and (2) Kit

12шт.

16

3006136X1

SPRING WASHER

EnglischBem: NOTE: Pos. (16) included in Pos. (1) and (2) Kit

12шт.

17

339365X1

SCREW

EnglischBem: NOTE: Pos. (17) included in Pos. (1) and (2) Kit

12шт.

18

3071028M1

ADJUSTMENT

EnglischBem: NOTE: Pos. (18) included in Pos. (1) and (2) Kit

2шт.

19

HOUSING

EnglischBem: ORDER 3071 028 M1

2шт.

20

3071029M1

BELLOWS

DeutschDesc: FALTENBALG

4шт.

21

3071030M1

SCREW

DeutschDesc: SCHRAUBE

2шт.

22

3071031M1

SCREW

DeutschDesc: SCHRAUBE

2шт.

23

1440477X1

CIRCLIP

EnglischBem: NOTE: Pos. (23) included in Pos. (1) and (2) Kit

2шт.

24

3071026M1

DISC

EnglischBem: NOTE: Pos. (24) included in Pos. (1) and (2) Kit

2шт.

25

3071041M1

SEAL

EnglischBem: NOTE: Pos. (25) included in Pos. (1) and (2) Kit

2шт.

26

3071025M1

BUSHING

EnglischBem: NOTE: Pos. (26) included in Pos. (1) and (2) Kit

2шт.

27

339003X1

LUBRICATION NIPPLE

EnglischBem: NOTE: Pos. (27) included in Pos. (1) and (2) Kit

2шт.

28

3071024M1

BUSHING

EnglischBem: NOTE: Pos. (28) included in Pos. (1) and (2) Kit

2шт.

29

1444892X1

O-RING

EnglischBem: NOTE: Pos. (29) included in Pos. (1) and (2) Kit

2шт.

30

3071027M1

BACK-UP RING

EnglischBem: NOTE: Pos. (30) included in Pos. (1) and (2) Kit

2шт.

31

3236325M1

SHAFT

EnglischBem: REPAIRS AND REPLACES 2962 961 M1 NOTE: Pos. (31) included in Pos

2шт.

32

3236326M1

CAM

EnglischBem: RIGHT 3236 326 M1 + 3236 325 M1 TO BE INSTALLED TOGETHER

1шт.

33

3236327M1

CAM

EnglischBem: LEFT 3236 327 M1 + 3236 325 M1 TO BE INSTALLED TOGETHER

1шт.

34

3236002M91

BRAKE SHOE

EnglischBem: NOTE: Pos. (34) included in Pos. (1) and (2) Kit

4шт.

35

3236033M91

BRAKE SHOE

EnglischBem: THICKNESS I NOTE: Pos. (35) included in Pos. (1) and (2) Kit

4шт.

36

3236035M91

BRAKE SHOE

EnglischBem: THICKNESS II NOTE: Pos. (36) included in Pos. (1) and (2) Kit

4шт.

37

3071036M1

PEG

EnglischBem: NOTE: Pos. (37) included in Pos. (1) and (2) Kit

8шт.

38

2943900M1

SPRING SEAT

EnglischBem: NOTE: Pos. (38) included in Pos. (1) and (2) Kit

16шт.

39

2949705M1

COMPRESSION SPRING

EnglischBem: NOTE: Pos. (39) included in Pos. (1) and (2) Kit

8шт.

40

390972X1

PLAIN WASHER

EnglischBem: NOTE: Pos. (40) included in Pos. (1) and (2) Kit

8шт.

41

1440256X1

CASTLE NUT

EnglischBem: NOTE: Pos. (41) included in Pos. (1) and (2) Kit

8шт.

42

391400X1

COTTER

EnglischBem: NOTE: Pos. (42) included in Pos. (1) and (2) Kit

8шт.

43

2943902M1

STRAP

EnglischBem: NOTE: Pos. (43) included in Pos. (1) and (2) Kit

2шт.

44

NOT USED

DeutschDesc: NICHT VERWENDET

-1шт.

45

339081X1

SCREW

EnglischBem: NOTE: Pos. (45) included in Pos. (1) and (2) Kit

4шт.

46

3006136X1

SPRING WASHER

EnglischBem: NOTE: Pos. (46) included in Pos. (1) and (2) Kit

4шт.

47

3071034M1

TENSION SPRING

EnglischBem: NOTE: Pos. (47) included in Pos. (1) and (2) Kit

4шт.

48

3071035M1

TENSION SPRING

EnglischBem: NOTE: Pos. (48) included in Pos. (1) and (2) Kit

2шт.
