Запчасти Komatsu 77C ЗАДН. МОСТ, ТОРМОЗ., DISC ТОРМОЗ. ТРАНСМИССИЯ И ЗАДН. МОСТ
№
Артикул
Название
Примечание
Количество
1
3236284M91
DISC BRAKE
EnglischBem: LEFT
1шт.
2
3236283M91
DISC BRAKE
EnglischBem: RIGHT
1шт.
3
BRAKE SADDLE
EnglischBem: ORDER 3236 284 M91
1шт.
4
BRAKE SADDLE
EnglischBem: ORDER 3236 283 M91
1шт.
5
3235406M91
BRAKE LINING
EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (2) Kit
8шт.
6
3235199M1
COVER
EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (2) Kit
2шт.
7
3230096M1
SLIDE
EnglischBem: NOTE: Pos. (7) included in Pos. (1) and (2) Kit
4шт.
8
3230027M1
SPRING
EnglischBem: NOTE: Pos. (8) included in Pos. (1) and (2) Kit
4шт.
9
3235194M1
COVER
EnglischBem: NOTE: Pos. (9) included in Pos. (1) and (2) Kit
2шт.
10
339282X1
SCREW
EnglischBem: NOTE: Pos. (10) included in Pos. (1) and (2) Kit
16шт.
11
390734X1
PLAIN WASHER
EnglischBem: NOTE: Pos. (11) included in Pos. (1) and (2) Kit
16шт.
12
3236288M91
PISTON KIT
EnglischBem: NOTE: Pos. (12) included in Pos. (1) and (2) Kit
4шт.
13
STRIPPER
EnglischBem: BELONGS TO SEAL KIT 3236 289 M91 NOTE: Pos. (13) included in Pos
8шт.
14
SEAL
EnglischBem: BELONGS TO SEAL KIT 3236 289 M91 NOTE: Pos. (14) included in Pos
8шт.
15
CAP
EnglischBem: BELONGS TO SEAL KIT 3236 289 M91 SI 2500/85-8 NOTE: Pos. (15) in
8шт.
16
O-RING
EnglischBem: BELONGS TO SEAL KIT 3236 289 M91 NOTE: Pos. (16) included in Pos
4шт.
17
3236287M1
COVER
EnglischBem: NOTE: Pos. (17) included in Pos. (1) and (2) Kit
2шт.
18
3236286M1
COVER
EnglischBem: NOTE: Pos. (18) included in Pos. (1) and (2) Kit
2шт.
19
3075672M1
SCREW
EnglischBem: NOTE: Pos. (19) included in Pos. (1) and (2) Kit
24шт.
20
1443790X1
SPRING WASHER
EnglischBem: NOTE: Pos. (20) included in Pos. (1) and (2) Kit
24шт.
21
2950552M1
VALVE
EnglischBem: NOTE: Pos. (21) included in Pos. (1) and (2) Kit
8шт.
22
VALVE
EnglischBem: ORDER 2950 552 M1
8шт.
23
3076886M1
DUST CAP
DeutschDesc: STAUBKAPPE
8шт.
24
3236289M91
GASKET KIT
DeutschDesc: DICHTUNGSSATZ
-26шт.
Выбрано товаров: 24
