Запчасти Komatsu 70E ГИДРОТРАНСФОРМАТОР ТРАНСМИССИЯ И ЗАДН. МОСТ

1

4401527M91

CONVERTOR

EnglischBem: WITHOUT BRAKE FREE WHEELER

1шт.

2

4401524M91

CONVERTOR

EnglischBem: WITH BRAKE FREE WHEELER

1шт.

3

339337X1

SCREW

EnglischBem: NOTE: Pos. (3) included in Pos. (1) and (2) Kit

1шт.

4

2904239M1

DISC

EnglischBem: NOTE: Pos. (4) included in Pos. (1) and (2) Kit

2шт.

5

2904241M1

DISC

EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (2) Kit

5шт.

6

3008932X1

SCREW

EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (2) Kit

1шт.

7

4907504M1

COVER

DeutschDesc: DECKEL

1шт.

7A

4910126M91

FREE WHEEL

DeutschDesc: FREILAUF

1шт.

8

4907505M1

COVER

DeutschDesc: DECKEL

1шт.

9

2995678X1

O-RING

EnglischBem: REPAIRS AND REPLACES 4907 506 M1 NOTE: Pos. (9) included in Pos.

1шт.

10

4907507M1

DISC

EnglischBem: NOTE: Pos. (10) included in Pos. (1) and (7A) Kit

1шт.

11

4907508M1

FREE WHEEL HUB

DeutschDesc: FREILAUFNABE

1шт.

12

2993499X1

ROLLER

DeutschDesc: ROLLE

15шт.

13

4907509M1

SPRING

DeutschDesc: FEDER

15шт.

14

4907510M1

PIN

DeutschDesc: BOLZEN

15шт.

15

4907511M1

DISTANCE PIECE

DeutschDesc: DISTANZSTUECK

1шт.

16

4907512M1

DISC

DeutschDesc: SCHEIBE

1шт.

17

2993498X1

BALL BEARING

EnglischBem: NOTE: Pos. (17) included in Pos. (1) and (2) Kit

1шт.

18

1441458X1

CIRCLIP

EnglischBem: NOTE: Pos. (18) included in Pos. (1) and (2) Kit

1шт.

19

4905301M1

CONVERTER SHELL

EnglischBem: NOTE: Pos. (19) included in Pos. (1) and (2) Kit

1шт.

20

4910127M1

TURBINE WHEEL

EnglischBem: REPAIRS AND REPLACES 4907 513 M1 NOTE: Pos. (20) included in Pos

1шт.

21

4907514M1

IDLER

EnglischBem: NOTE: Pos. (21) included in Pos. (1) and (2) Kit

1шт.

22

3241228M1

CIRCLIP

EnglischBem: NOTE: Pos. (22) included in Pos. (1) and (2) Kit

1шт.

23

2995766X1

CIRCLIP

EnglischBem: NOTE: Pos. (23) included in Pos. (1) and (2) Kit

2шт.

24

2995676X1

BALL BEARING

EnglischBem: NOTE: Pos. (24) included in Pos. (1) and (2) Kit

1шт.

25

390455X1

CIRCLIP

EnglischBem: NOTE: Pos. (25) included in Pos. (1) and (2) Kit

1шт.

26

2995680X1

O-RING

EnglischBem: NOTE: Pos. (26) included in Pos. (1) and (2) Kit

1шт.

27

4907515M1

SCREW

EnglischBem: NOTE: Pos. (27) included in Pos. (1) and (2) Kit

16шт.

28

4907516M1

PLAIN WASHER

EnglischBem: NOTE: Pos. (28) included in Pos. (1) and (2) Kit

16шт.

29

4907517M1

PUMP GEAR

EnglischBem: NOTE: Pos. (29) included in Pos. (1) and (2) Kit

1шт.

30

3002128X1

PLAIN WASHER

EnglischBem: NOTE: Pos. (30) included in Pos. (1) and (2) Kit

30шт.

31

339337X1

SCREW

EnglischBem: NOTE: Pos. (31) included in Pos. (1) and (2) Kit

30шт.

32

4907518M1

O-RING

EnglischBem: NOTE: Pos. (32) included in Pos. (1) and (2) Kit

1шт.

33

4907519M1

FLANGE

EnglischBem: NOTE: Pos. (33) included in Pos. (1) and (2) Kit

1шт.
