Запчасти Komatsu 70E ЦИЛИНДР КОВША ГИДРАВЛИКА

1

4501048M91

BUCKET CYLINDER

EnglischBem: REPAIRS AND REPLACES 4500 999 M91 LEFT HAND

1шт.

2

4501047M91

BUCKET CYLINDER

EnglischBem: REPAIRS AND REPLACES 4500 998 M91 RIGHT HAND

1шт.

3

4919525M91

CYLINDER HOUSING

EnglischBem: REPAIRS AND REPLACES 4917 900 M91

1шт.

4

4919524M91

CYLINDER HOUSING

EnglischBem: REPAIRS AND REPLACES 4917 901 M91

1шт.

4A

4200687M1

BUSHING

EnglischBem: NOTE: Pos. (4A) included in Pos. (3) and (4) Kit

2шт.

4B

2907100M1

RING

EnglischBem: NOTE: Pos. (4B) included in Pos. (3) and (4) Kit

1шт.

5

4919526M91

CYLINDER ROD

EnglischBem: REPAIRS AND REPLACES 4917 902 M91

1шт.

5A

4919523M91

CYLINDER ROD

EnglischBem: WITH STRAP FOR RETURN TO DIG

1шт.

5B

4200688M1

BUSHING

EnglischBem: NOTE: Pos. (5B) included in Pos. (5) and (5A) Kit

1шт.

6

4915637M1

GUIDE BUSH

EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (2) Kit

1шт.

7

NOT USED

DeutschDesc: NICHT VERWENDET

-1шт.

8

4915639M1

STRIPPER

EnglischBem: BELONGS TO SEAL KIT 4915 638 M91 NOTE: Pos. (8) included in Pos.

1шт.

9

4915640M1

SEAL

EnglischBem: BELONGS TO SEAL KIT 4915 638 M91 NOTE: Pos. (9) included in Pos.

1шт.

9A

4915641M1

SEAL

EnglischBem: BELONGS TO SEAL KIT 4915 638 M91 NOTE: Pos. (9A) included in Pos

1шт.

10

4915643M1

TAB WASHER

EnglischBem: NOTE: Pos. (10) included in Pos. (1) and (2) Kit

1шт.

10A

4919527M1

O-RING

EnglischBem: BELONGS TO SEAL KIT 4915 638 M91 NOTE: Pos. (10A) included in Po

1шт.

11

3235596M1

BACK-UP RING

EnglischBem: BELONGS TO SEAL KIT 4915 638 M91 NOTE: Pos. (11) included in Pos

1шт.

12

3235597M1

O-RING

EnglischBem: BELONGS TO SEAL KIT 4915 638 M91 NOTE: Pos. (12) included in Pos

1шт.

13

4915642M1

PILOT

EnglischBem: BELONGS TO SEAL KIT 4915 638 M91 NOTE: Pos. (13) included in Pos

1шт.

14

4915644M1

PISTON

EnglischBem: NOTE: Pos. (14) included in Pos. (1) and (2) Kit

1шт.

15

3402928M1

GRUB SCREW

EnglischBem: BELONGS TO SEAL KIT 4915 638 M91 NOTE: Pos. (15) included in Pos

1шт.

16

3235599M1

PILOT

EnglischBem: BELONGS TO SEAL KIT 4915 638 M91 NOTE: Pos. (16) included in Pos

2шт.

17

4915645M1

SEAL

EnglischBem: BELONGS TO SEAL KIT 4915 638 M91 NOTE: Pos. (17) included in Pos

1шт.

18

359191X1

O-RING

EnglischBem: BELONGS TO SEAL KIT 4915 638 M91 NOTE: Pos. (18) included in Pos

1шт.

19

339608X1

LUBRICATION NIPPLE

EnglischBem: NOTE: Pos. (19) included in Pos. (1) and (2) Kit

2шт.

20

NOT USED

DeutschDesc: NICHT VERWENDET

-1шт.

21

4915638M91

GASKET KIT

DeutschDesc: DICHTUNGSSATZ

-26шт.
