Запчасти Komatsu 70E УДАЛЕНН. УПРАВЛЯЮЩ. КЛАПАН, TWO WAYS ГИДРАВЛИКА

1

4201477M91

REMOTE CONTROL VALVE

EnglischBem: WITHOUT RETURN TO DIG

1шт.

1A

4203025M91

REMOTE CONTROL VALVE

EnglischBem: WITH RETURN TO DIG

1шт.

1B

HOUSING

EnglischBem: ORDER 4201 447 M91 ORDER 4203 025 M91 NOTE: Pos. (1B) included i

1шт.

2

4913237M1

SEAL

EnglischBem: NOTE: Pos. (2) included in Pos. (1) and (1A) Kit

2шт.

3

3077642M1

BRACKET

EnglischBem: NOTE: Pos. (3) included in Pos. (1) and (1A) Kit

2шт.

4

4907616M1

STRIPPER

EnglischBem: NOTE: Pos. (4) included in Pos. (1) and (1A) Kit

2шт.

5

1892748M1

FLANGE

EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (1A) Kit

1шт.

6

2949238M1

BALL HEAD

EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (1A) Kit

1шт.

7

2949239M1

SCREW

EnglischBem: NOTE: Pos. (7) included in Pos. (1) and (1A) Kit

1шт.

8

3077648M1

LEVER

EnglischBem: NOTE: Pos. (8) included in Pos. (1) and (1A) Kit

1шт.

9

1892746M1

HOUSING

EnglischBem: NOTE: Pos. (9) included in Pos. (1) and (1A) Kit

1шт.

10

3235389M1

SCREW

EnglischBem: NOTE: Pos. (10) included in Pos. (1) and (1A) Kit

1шт.

11

390972X1

PLAIN WASHER

EnglischBem: NOTE: Pos. (11) included in Pos. (1) and (1A) Kit

3шт.

12

3077645M1

LATCH

EnglischBem: NOTE: Pos. (12) included in Pos. (1) and (1A) Kit

1шт.

13

2949234M1

SCREW

EnglischBem: NOTE: Pos. (13) included in Pos. (1) and (1A) Kit

1шт.

14

1892565M1

SCREW

EnglischBem: NOTE: Pos. (14) included in Pos. (1) and (1A) Kit

1шт.

15

2949233M1

SPRING

EnglischBem: NOTE: Pos. (15) included in Pos. (1) and (1A) Kit

1шт.

16

1892747M1

GRIP

EnglischBem: NOTE: Pos. (16) included in Pos. (1) and (1A) Kit

1шт.

17

2949231M1

ADAPTER SLEEVES

EnglischBem: NOTE: Pos. (17) included in Pos. (1) and (1A) Kit

1шт.

18

3031752M1

BRACE

EnglischBem: NOTE: Pos. (18) included in Pos. (1) and (1A) Kit

1шт.

19

2949230M1

BELLOWS

EnglischBem: NOTE: Pos. (19) included in Pos. (1) and (1A) Kit

1шт.
