Запчасти Komatsu 70E ПРИВОДRS СИДЕНЬЕ ШАССИ И SUPERSTRUCTURE

Схема запчастей Komatsu 70E - ПРИВОДRS СИДЕНЬЕ ШАССИ И SUPERSTRUCTURE
28A
1
1
2
2
29A
34
28B
8A
14
4
3
10
11
12
9
13
10
5
23
24
6
12
22
11
25
12
29
15
26
29
12
16
17
12
18
30
19
27
21
20
8
12
7
29
28
29
36
12
35
32
12
33
31
27A

Артикул

Название

Примечание

Количество

1

4201933M92

SEAT

DeutschDesc: SITZ

1шт.

2

4202052M92

SEAT

EnglischBem: WATER PROTECTED

1шт.

3

3252484M91

BACK REST

DeutschDesc: RUECKENLEHNE

1шт.

4

3252498M91

BACK REST

EnglischBem: WATER PROTECTED

1шт.

5

4908568M91

SEAT CUSHION

EnglischBem: REPAIRS AND REPLACES 3252 485 M91

1шт.

6

3252499M91

SEAT CUSHION

EnglischBem: WATER PROTECTED

1шт.

7

4909918M91

BOTTOM PART

EnglischBem: REPAIRS AND REPLACES 3252 486 M91 NOTE: Pos. (7) included in Pos

1шт.

8

3067402M8

SCREW

EnglischBem: EXECUTION I NOTE: Pos. (8) included in Pos. (1) and (2) Kit

2шт.

8A

3005720X1

SCREW

EnglischBem: EXECUTION II NOTE: Pos. (8A) included in Pos. (1) and (2) Kit

2шт.

9

339124X1

SCREW

EnglischBem: NOTE: Pos. (9) included in Pos. (1) and (2) Kit

2шт.

10

3252487M1

COVERING

EnglischBem: NOTE: Pos. (10) included in Pos. (1) and (2) Kit

2шт.

11

339123X1

SCREW

EnglischBem: NOTE: Pos. (11) included in Pos. (1) and (2) Kit

4шт.

12

1443789X1

SPRING WASHER

EnglischBem: REPAIRS AND REPLACES 339 347 X1 NOTE: Pos. (12) included in Pos.

8шт.

13

3252488M1

ARM REST

DeutschDesc: ARMLEHNE

1шт.

14

3252501M1

ARM REST

EnglischBem: WATER PROTECTED

1шт.

15

3252489M1

ARM REST

DeutschDesc: ARMLEHNE

1шт.

16

3252502M1

ARM REST

EnglischBem: WATER PROTECTED

1шт.

17

3252490M1

GRIP

EnglischBem: NOTE: Pos. (17) included in Pos. (1) and (2) Kit

1шт.

18

3252491M1

GRIP

EnglischBem: NOTE: Pos. (18) included in Pos. (1) and (2) Kit

1шт.

19

3252492M1

GRIP

EnglischBem: NOTE: Pos. (19) included in Pos. (1) and (2) Kit

1шт.

20

3252493M91

GRIP

EnglischBem: NOTE: Pos. (20) included in Pos. (1) and (2) Kit

1шт.

21

391566X1

SLEEVE

EnglischBem: NOTE: Pos. (21) included in Pos. (1) and (2) Kit

1шт.

22

4909919M91

DAMPER

EnglischBem: REPAIRS AND REPLACES 3252 494 M91 NOTE: Pos. (22) included in Po

1шт.

23

339010X1

SCREW

EnglischBem: NOTE: Pos. (23) included in Pos. (1) and (2) Kit

2шт.

24

3252478M1

TUBE

EnglischBem: NOTE: Pos. (24) included in Pos. (1) and (2) Kit

2шт.

25

1444329X1

NUT

EnglischBem: NOTE: Pos. (25) included in Pos. (1) and (2) Kit

2шт.

26

3252479M1

TENSION SPRING

EnglischBem: NOTE: Pos. (26) included in Pos. (1) and (2) Kit

2шт.

27

3252495M1

RAIL

EnglischBem: EXECUTION I NOTE: Pos. (27) included in Pos. (1) and (2) Kit

1шт.

27A

4909913M91

RAIL

EnglischBem: EXECUTION II NOTE: Pos. (27A) included in Pos. (1) and (2) Kit

1шт.

28

3252496M91

RAIL

EnglischBem: EXECUTION I NOTE: Pos. (28) included in Pos. (1) and (2) Kit

1шт.

28A

4909912M91

RAIL

EnglischBem: EXECUTION II NOTE: Pos. (28A) included in Pos. (1) and (2) Kit

1шт.

28B

4909920M1

STIRRUP

EnglischBem: EXECUTION II NOTE: Pos. (28B) included in Pos. (1) and (2) Kit

1шт.

29

3005453X1

SCREW

EnglischBem: EXECUTION I NOTE: Pos. (29) included in Pos. (1) and (2) Kit

4шт.

29A

1442324X1

SCREW

EnglischBem: EXECUTION II NOTE: Pos. (29A) included in Pos. (1) and (2) Kit

4шт.

30

4202104M91

SAFETY BELT

DeutschDesc: SICHERHEITSGURT

1шт.

31

339168X1

SCREW

EnglischBem: EXECUTION I

4шт.

32

3073369M1

DISC

EnglischBem: EXECUTION I

8шт.

33

1443789X1

SPRING WASHER

EnglischBem: EXECUTION I

4шт.

34

3008354X1

SAFETY CATCH

EnglischBem: EXECUTION II NOTE: Pos. (34) included in Pos. (1) and (2) Kit

2шт.

35

4909915M1

SPRING

EnglischBem: EXECUTION II NOTE: Pos. (35) included in Pos. (1) and (2) Kit

1шт.

36

4909916M1

SPRING

EnglischBem: EXECUTION II NOTE: Pos. (36) included in Pos. (1) and (2) Kit

1шт.

Выбрано товаров: 41
