Запчасти Komatsu 70E МОСТ INSERT, ПЕРЕДНИЙ МОСТ СИСТЕМАУПРАВЛЕНИЯ ПОВОРОТОМ, ПЕРЕДНИЙ МОСТ, ТОРМОЗ. СИСТЕМА

1

4909599M91

AXLE INSERT

SN: 376020373

1шт.

1A

4919656M91

AXLE INSERT

SN: 376020374-UP

1шт.

2

3235498M1

HOUSING

SN: 376020373

1шт.

2A

4915075M1

HOUSING

SN: 376020374-UP

1шт.

3

4917312M91

DRIVE

EnglischBem: REPAIRS AND REPLACES 3235 444 M91 NOTE: Pos. (3) included in Pos

1шт.

4

4909575M1

ROLLER BEARING

EnglischBem: REPAIRS AND REPLACES 2335 416 M1 NOTE: Pos. (4) included in Pos.

1шт.

5

3235432M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 1,5 MM NOTE: Pos. (5) included in Pos. (1) and (1A) Ki

-26шт.

6

3235433M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 1,3 MM NOTE: Pos. (6) included in Pos. (1) and (1A) Ki

-26шт.

7

3235434M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 1,2 MM NOTE: Pos. (7) included in Pos. (1) and (1A) Ki

-26шт.

8

3235435M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 1,0 MM NOTE: Pos. (8) included in Pos. (1) and (1A) Ki

-26шт.

9

3235436M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 0,9 MM NOTE: Pos. (9) included in Pos. (1) and (1A) Ki

-26шт.

10

3235437M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 0,8 MM NOTE: Pos. (10) included in Pos. (1) and (1A) K

-26шт.

11

3235438M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 0,7 MM NOTE: Pos. (11) included in Pos. (1) and (1A) K

-26шт.

12

339193X1

ADAPTER SLEEVES

EnglischBem: NOTE: Pos. (12) included in Pos. (1) and (1A) Kit

2шт.

12A

4909265M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 9,0 MM NOTE: Pos. (12A) included in Pos. (1) and (1A)

-26шт.

12B

4909264M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 8,9 MM NOTE: Pos. (12B) included in Pos. (1) and (1A)

-26шт.

12C

4909263M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 8,8 MM NOTE: Pos. (12C) included in Pos. (1) and (1A)

-26шт.

12D

4909262M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 8,7 MM NOTE: Pos. (12D) included in Pos. (1) and (1A)

-26шт.

12E

4909261M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 8,6 MM NOTE: Pos. (12E) included in Pos. (1) and (1A)

-26шт.

12F

4909260M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 8,5 MM NOTE: Pos. (12F) included in Pos. (1) and (1A)

-26шт.

12G

4909259M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 8,4 MM NOTE: Pos. (12G) included in Pos. (1) and (1A)

-26шт.

12H

4909258M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 8,3 MM NOTE: Pos. (12H) included in Pos. (1) and (1A)

-26шт.

12I

4909257M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 8,2 MM NOTE: Pos. (12I) included in Pos. (1) and (1A)

-26шт.

12J

4909256M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 8,1 MM NOTE: Pos. (12J) included in Pos. (1) and (1A)

-26шт.

13

3235422M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 8,0 MM NOTE: Pos. (13) included in Pos. (1) and (1A) K

-26шт.

14

3235423M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 7,9 MM NOTE: Pos. (14) included in Pos. (1) and (1A) K

-26шт.

15

3235424M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 7,7 MM NOTE: Pos. (15) included in Pos. (1) and (1A) K

-26шт.

16

3235425M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 7,6 MM NOTE: Pos. (16) included in Pos. (1) and (1A) K

-26шт.

17

3235426M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 7,5 MM NOTE: Pos. (17) included in Pos. (1) and (1A) K

-26шт.

18

3235427M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 7,4 MM NOTE: Pos. (18) included in Pos. (1) and (1A) K

-26шт.

19

3235428M1

ADJUSTING COLLAR

EnglischBem: THICKNESS 7,3 MM NOTE: Pos. (19) included in Pos. (1) and (1A) K

-26шт.

20

4909577M1

ROLLER BEARING

EnglischBem: REPAIRS AND REPLACES 3235 429 M1 NOTE: Pos. (20) included in Pos

1шт.

21

NOT USED

DeutschDesc: NICHT VERWENDET

-1шт.

22

3235431M1

SHAFT SEAL

EnglischBem: NOTE: Pos. (22) included in Pos. (1) and (1A) Kit REPAIRS AND RE

1шт.

23

3235443M1

SHEET

EnglischBem: NOTE: Pos. (23) included in Pos. (1) and (1A) Kit REPAIRS AND RE

1шт.

24

3235501M1

DRIVE FLANGE

EnglischBem: NOTE: Pos. (24) included in Pos. (1) and (1A) Kit REPAIRS AND RE

1шт.

25

3235502M1

SCREW

EnglischBem: NOTE: Pos. (25) included in Pos. (1) and (1A) Kit REPAIRS AND RE

8шт.

26

3235440M1

DISC

EnglischBem: NOTE: Pos. (26) included in Pos. (1) and (1A) Kit REPAIRS AND RE

1шт.

27

3235439M1

TAB WASHER

EnglischBem: NOTE: Pos. (27) included in Pos. (1) and (1A) Kit REPAIRS AND RE

1шт.

28

4909249M1

NUT

EnglischBem: NOTE: Pos. (28) included in Pos. (1) and (1A) Kit REPAIRS AND RE

1шт.

29

4909578M1

ROLLER BEARING

EnglischBem: REPAIRS AND REPLACES 3235 420 M1 NOTE: Pos. (29) included in Pos

1шт.

30

NOT USED

DeutschDesc: NICHT VERWENDET

-1шт.

31

3235419M1

ROLLER BEARING

EnglischBem: NOTE: Pos. (31) included in Pos. (1) and (1A) Kit REPAIRS AND RE

1шт.

32

3231079M1

ADJUSTING NUT

EnglischBem: NOTE: Pos. (32) included in Pos. (1) and (1A) Kit REPAIRS AND RE

2шт.

33

4918809M91

DIFFERENTIAL

EnglischBem: REPAIRS AND REPLACES 3235 503 M91 NOTE: Pos. (33) included in Po

1шт.

|$51

DIFFERENTIAL

DeutschDesc: DIFFERENTIAL

-3шт.

33A

4919476M91

DIFFERENTIAL

EnglischBem: PI 040-94-14

1шт.

|$52

DIFFERENTIAL

DeutschDesc: DIFFERENTIAL

-3шт.

34

2943909M1

TAB WASHER

DeutschDesc: SICHERUNGSBLECH

1шт.

35

1443681X1

SCREW

DeutschDesc: SCHRAUBE

2шт.

36

3236184M1

SCREW

EnglischBem: 35 MM

20шт.

37

4919484M1

SCREW

EnglischBem: 50 MM

20шт.
