Запчасти Komatsu 66C ЦИЛИНДР КОВША ГИДРАВЛИКА

1

1608142M91

BUCKET CYLINDER

EnglischBem: LEFT HAND SEAL KIT, SEE 4272

1шт.

2

1608143M91

BUCKET CYLINDER

EnglischBem: RIGHT HAND SEAL KIT, SEE 4272

1шт.

2A

1609566M92

HOUSING

EnglischBem: NOTE: Pos. (2A) included in Pos. (1) and (2) Kit

1шт.

3

HOUSING

EnglischBem: ORDER 1609 566 M92

1шт.

4

1608878M1

BUSHING

DeutschDesc: BUCHSE

2шт.

5

1608879M1

RING

DeutschDesc: RING

1шт.

6

1608854M91

CYLINDER ROD

EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (2) Kit

1шт.

7

CYLINDER ROD

EnglischBem: ORDER 1608 854 M92

1шт.

8

1608895M1

BUSHING

DeutschDesc: BUCHSE

2шт.

9

1608896M1

RING

DeutschDesc: RING

1шт.

10

1609570M1

BUSHING

EnglischBem: NOTE: Pos. (10) included in Pos. (1) and (2) Kit

1шт.

11

1607859M1

STRIPPER

EnglischBem: NOTE: Pos. (11) included in Pos. (1) and (2) Kit

1шт.

12

1607861M1

SEAL

EnglischBem: NOTE: Pos. (12) included in Pos. (1) and (2) Kit

1шт.

13

1608834M1

BEARING

EnglischBem: NOTE: Pos. (13) included in Pos. (1) and (2) Kit

1шт.

14

1608629M1

TAB WASHER

EnglischBem: NOTE: Pos. (14) included in Pos. (1) and (2) Kit

1шт.

15

1089309M1

BOOT

EnglischBem: NOTE: Pos. (15) included in Pos. (1) and (2) Kit

1шт.

16

359209X1

O-RING

EnglischBem: NOTE: Pos. (16) included in Pos. (1) and (2) Kit

1шт.

17

1609571M2

PISTON

EnglischBem: NOTE: Pos. (17) included in Pos. (1) and (2) Kit

1шт.

18

359193X1

O-RING

EnglischBem: NOTE: Pos. (18) included in Pos. (1) and (2) Kit

1шт.

19

1606818M1

RING

EnglischBem: NOTE: Pos. (19) included in Pos. (1) and (2) Kit

2шт.

20

1607702M1

BACK-UP RING

EnglischBem: NOTE: Pos. (20) included in Pos. (1) and (2) Kit

1шт.

21

359208X1

O-RING

EnglischBem: NOTE: Pos. (21) included in Pos. (1) and (2) Kit

1шт.

22

1089290M1

SEAL

EnglischBem: NOTE: Pos. (22) included in Pos. (1) and (2) Kit

1шт.

23

1607699M1

NUT

EnglischBem: NOTE: Pos. (23) included in Pos. (1) and (2) Kit

1шт.

24

339608X1

LUBRICATION NIPPLE

EnglischBem: NOTE: Pos. (24) included in Pos. (1) and (2) Kit

2шт.

25

NOT USED

DeutschDesc: NICHT VERWENDET

-1шт.

26

1608856M92

PIPE

DeutschDesc: ROHRLEITUNG

1шт.

27

1608857M92

PIPE

DeutschDesc: ROHRLEITUNG

1шт.

28

1608858M92

PIPE

DeutschDesc: ROHRLEITUNG

1шт.

29

1608859M92

PIPE

DeutschDesc: ROHRLEITUNG

1шт.

30

359305X1

O-RING

EnglischBem: NOTE: Pos. (30) included in Pos. (1) and (2) Kit

2шт.

31

359307X1

O-RING

EnglischBem: NOTE: Pos. (31) included in Pos. (1) and (2) Kit

2шт.

32

391681X1

SCREW

EnglischBem: NOTE: Pos. (32) included in Pos. (1) and (2) Kit

12шт.

33

339376X1

SPRING WASHER

EnglischBem: NOTE: Pos. (33) included in Pos. (1) and (2) Kit

12шт.

34

1441436X1

SCREW

EnglischBem: NOTE: Pos. (34) included in Pos. (1) and (2) Kit

8шт.

35

391241X1

SPRING WASHER

EnglischBem: NOTE: Pos. (35) included in Pos. (1) and (2) Kit

8шт.

36

1440099X1

NUT

EnglischBem: NOTE: Pos. (36) included in Pos. (1) and (2) Kit

4шт.
