Запчасти Komatsu 66C ЗАДН. МОСТ, ТОРМОЗ., DISC ТОРМОЗ. ТРАНСМИССИЯ И ЗАДН. МОСТ

1

3235186M91

DISC BRAKE

EnglischBem: LEFT HAND COMPLETELY INTERCHANGEABLE WITH 3236 280 M91 / 3236 28

1шт.

2

3235185M91

DISC BRAKE

EnglischBem: RIGHT HAND COMPLETELY INTERCHANGEABLE WITH 3236 280 M91 / 3236 2

1шт.

3

BRAKE SADDLE

EnglischBem: ORDER 3235 186 M91

1шт.

4

BRAKE SADDLE

EnglischBem: ORDER 3235 185 M91

1шт.

5

3235406M91

BRAKE LINING

EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (2) Kit

8шт.

5A

3235265M91

BRAKE LINING

EnglischBem: SPECIAL EQUIPMENT, TO BE EXCHANGED IN KITS ONLY 20 PIECES

8шт.

6

3235199M1

COVER

EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (2) Kit

2шт.

7

3230096M1

SLIDE

EnglischBem: NOTE: Pos. (7) included in Pos. (1) and (2) Kit

4шт.

7A

3230027M1

SPRING

EnglischBem: NOTE: Pos. (7A) included in Pos. (1) and (2) Kit

4шт.

8

3235194M1

COVER

EnglischBem: NOTE: Pos. (8) included in Pos. (1) and (2) Kit

2шт.

9

339282X1

SCREW

EnglischBem: NOTE: Pos. (9) included in Pos. (1) and (2) Kit

16шт.

9A

390734X1

PLAIN WASHER

EnglischBem: NOTE: Pos. (9A) included in Pos. (1) and (2) Kit

16шт.

10

3230126M91

PISTON KIT

EnglischBem: NOTE: Pos. (10) included in Pos. (1) and (2) Kit

4шт.

11

3075669M1

STRIPPER

EnglischBem: BELONGS TO SEAL KIT 3235 188 M91 NOTE: Pos. (11) included in Pos

8шт.

12

3075668M1

SEAL

EnglischBem: BELONGS TO SEAL KIT 3235 188 M91 NOTE: Pos. (12) included in Pos

8шт.

13

3235192M1

COVER

EnglischBem: NOTE: Pos. (13) included in Pos. (1) and (2) Kit

2шт.

13A

3235193M1

COVER

EnglischBem: NOTE: Pos. (13A) included in Pos. (1) and (2) Kit

2шт.

14

3004932X1

O-RING

EnglischBem: BELONGS TO SEAL KIT 3235 188 M91 NOTE: Pos. (14) included in Pos

4шт.

15

3075672M1

SCREW

EnglischBem: NOTE: Pos. (15) included in Pos. (1) and (2) Kit

24шт.

16

1443790X1

SPRING WASHER

EnglischBem: NOTE: Pos. (16) included in Pos. (1) and (2) Kit

24шт.

17

2950552M1

VALVE

EnglischBem: NOTE: Pos. (17) included in Pos. (1) and (2) Kit

6шт.

18

VALVE

EnglischBem: ORDER 2950 552 M1

6шт.

19

3076886M1

CAP

DeutschDesc: KAPPE

6шт.

20

3235188M91

GASKET KIT

EnglischBem: FOR ONE PISTON KIT

-26шт.
