Запчасти Komatsu 60E ГИДРОЦИЛИНДР ПОДЪЕМА ГИДРАВЛИКА

1

4500941M91

LIFT CYLINDER

EnglischBem: LEFT HAND

1шт.

2

4500940M91

LIFT CYLINDER

EnglischBem: RIGHT HAND

1шт.

3

4909942M91

CYLINDER HOUSING

EnglischBem: EXECUTION I

1шт.

3A

3232482M91

CYLINDER HOUSING

EnglischBem: EXECUTION II

1шт.

4

4909943M91

CYLINDER HOUSING

EnglischBem: EXECUTION I

1шт.

4A

3232483M91

CYLINDER HOUSING

EnglischBem: EXECUTION II

1шт.

5

4909944M91

CYLINDER ROD

EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (2) Kit

1шт.

6

4909945M1

GUIDE BUSH

EnglischBem: EXECUTION I FLANGE THICKNESS 12 MM NOTE: Pos. (6) included in Po

1шт.

6A

3232484M1

GUIDE BUSH

EnglischBem: EXECUTION II FLANGE THICKNESS 7 MM NOTE: Pos. (6A) included in P

1шт.

7

4909946M1

GASKET

EnglischBem: BELONGS TO SEAL KIT 4908 430 M91 NOTE: Pos. (7) included in Pos.

2шт.

8

4909947M1

PILOT

EnglischBem: BELONGS TO SEAL KIT 4908 430 M91 NOTE: Pos. (8) included in Pos.

2шт.

9

4909948M1

BACK-UP RING

EnglischBem: BELONGS TO SEAL KIT 4908 430 M91 NOTE: Pos. (9) included in Pos.

1шт.

10

4909964M1

O-RING

EnglischBem: BELONGS TO SEAL KIT 4908 430 M91 NOTE: Pos. (10) included in Pos

1шт.

11

2993752X1

GRUB SCREW

EnglischBem: EXECUTION I NOTE: Pos. (11) included in Pos. (1) and (2) Kit M5

1шт.

11A

2993819X1

GRUB SCREW

EnglischBem: EXECUTION II NOTE: Pos. (11A) included in Pos. (1) and (2) Kit M

1шт.

12

4909949M1

PISTON

EnglischBem: NOTE: Pos. (12) included in Pos. (1) and (2) Kit

1шт.

13

4909965M1

O-RING

EnglischBem: BELONGS TO SEAL KIT 4908 430 M91 NOTE: Pos. (13) included in Pos

1шт.

14

4909950M1

GASKET

EnglischBem: BELONGS TO SEAL KIT 4908 430 M91 NOTE: Pos. (14) included in Pos

1шт.

15

3005000X1

GRUB SCREW

EnglischBem: EXECUTION I NOTE: Pos. (15) included in Pos. (1) and (2) Kit M10

1шт.

15A

2993820X1

GRUB SCREW

EnglischBem: EXECUTION II NOTE: Pos. (15A) included in Pos. (1) and (2) Kit M

1шт.

16

4909951M1

TUBE

EnglischBem: NOTE: Pos. (16) included in Pos. (1) and (2) Kit

1шт.

17

339608X1

LUBRICATION NIPPLE

EnglischBem: NOTE: Pos. (17) included in Pos. (1) and (2) Kit

1шт.

18

3002304X91

UNION

EnglischBem: NOTE: Pos. (18) included in Pos. (1) and (2) Kit

1шт.

19

3002322X91

UNION

EnglischBem: NOTE: Pos. (19) included in Pos. (1) and (2) Kit

1шт.

20

1444829X1

O-RING

EnglischBem: BELONGS TO SEAL KIT 4908 430 M91 NOTE: Pos. (20) included in Pos

1шт.

21

4908430M91

GASKET KIT

DeutschDesc: DICHTUNGSSATZ

1шт.
