Запчасти Komatsu 55C ВЕНТИЛЯТОР, НАТЯЖИТЕЛЬ РЕМНЯ ДВИГАТЕЛЬ, АКСЕССУАРЫ И ЭЛЕКТРИЧ. СИСТЕМА

1

2871324M1

BEARING HOUSING

DeutschDesc: LAGERGEHAEUSE

1шт.

2

1443789X1

SPRING WASHER

DeutschDesc: FEDERRING

4шт.

3

339169X1

NUT

DeutschDesc: MUTTER

4шт.

4

2994459M1

CIRCLIP

DeutschDesc: SICHERUNGSRING

1шт.

5

2871323M1

SHAFT

DeutschDesc: WELLE

1шт.

6

1443778X1

SHIM

DeutschDesc: PASSSCHEIBE

1шт.

7

3001675X1

BALL BEARING

DeutschDesc: KUGELLAGER

1шт.

8

2871366M1

BUSHING

DeutschDesc: BUCHSE

1шт.

9

3001676X1

BALL BEARING

DeutschDesc: KUGELLAGER

1шт.

10

1444592X1

SEAL

DeutschDesc: DICHTRING

1шт.

11

1443862X1

SHIM

DeutschDesc: PASSSCHEIBE

1шт.

12

2999759M1

CIRCLIP

DeutschDesc: SICHERUNGSRING

1шт.

13

3070606M1

HUB

DeutschDesc: NABE

1шт.

14

2992692M1

PULLEY

DeutschDesc: RIEMENSCHEIBE

1шт.

15

2979651M1

DISTANCE PIECE

DeutschDesc: DISTANZSTUECK

1шт.

16

3079636M2

FAN

DeutschDesc: LUEFTER

1шт.

17

2871328M1

DISC

DeutschDesc: SCHEIBE

1шт.

18

1443789X1

SPRING WASHER

DeutschDesc: FEDERRING

4шт.

19

339159X1

SCREW

DeutschDesc: SCHRAUBE

4шт.

20

4004739M91

TUNNEL

EnglischBem: DOES NOT BELONG TO THE SUPPLY UNIT OF THE ENGINE

1шт.

21

4004915M91

ANGLE

EnglischBem: DOES NOT BELONG TO THE SUPPLY UNIT OF THE ENGINE

1шт.

22

339123X1

SCREW

EnglischBem: DOES NOT BELONG TO THE SUPPLY UNIT OF THE ENGINE

1шт.

23

1443789X1

SPRING WASHER

EnglischBem: DOES NOT BELONG TO THE SUPPLY UNIT OF THE ENGINE

1шт.

24

4004973M91

BRACKET

EnglischBem: DOES NOT BELONG TO THE SUPPLY UNIT OF THE ENGINE

1шт.

25

1444240X1

GRUB SCREW

EnglischBem: DOES NOT BELONG TO THE SUPPLY UNIT OF THE ENGINE

3шт.

26

339169X1

NUT

EnglischBem: DOES NOT BELONG TO THE SUPPLY UNIT OF THE ENGINE

11шт.

27

391039X1

PLAIN WASHER

EnglischBem: DOES NOT BELONG TO THE SUPPLY UNIT OF THE ENGINE

4шт.

28

4004971M1

ANGLE

EnglischBem: DOES NOT BELONG TO THE SUPPLY UNIT OF THE ENGINE

1шт.

29

339761X1

SCREW

EnglischBem: DOES NOT BELONG TO THE SUPPLY UNIT OF THE ENGINE

2шт.

30

391039X1

PLAIN WASHER

EnglischBem: DOES NOT BELONG TO THE SUPPLY UNIT OF THE ENGINE

4шт.

31

1443789X1

SPRING WASHER

EnglischBem: DOES NOT BELONG TO THE SUPPLY UNIT OF THE ENGINE

4шт.

32

339169X1

NUT

EnglischBem: DOES NOT BELONG TO THE SUPPLY UNIT OF THE ENGINE

4шт.

33

339337X1

SCREW

EnglischBem: DOES NOT BELONG TO THE SUPPLY UNIT OF THE ENGINE

2шт.

34

4005309M1

PLAIN WASHER

EnglischBem: DOES NOT BELONG TO THE SUPPLY UNIT OF THE ENGINE

4шт.

35

4004979M91

BRACKET

EnglischBem: DOES NOT BELONG TO THE SUPPLY UNIT OF THE ENGINE

1шт.

36

4004977M91

BRACKET

EnglischBem: DOES NOT BELONG TO THE SUPPLY UNIT OF THE ENGINE

1шт.

37

1442729X1

SCREW

EnglischBem: DOES NOT BELONG TO THE SUPPLY UNIT OF THE ENGINE

4шт.

38

1443796X1

SPRING WASHER

EnglischBem: DOES NOT BELONG TO THE SUPPLY UNIT OF THE ENGINE

4шт.

39

4200231M1

GASKET

EnglischBem: DOES NOT BELONG TO THE SUPPLY UNIT OF THE ENGINE

1шт.
